Microchip 1200 V 30 A Schottky Barrier Diode, 1.8 V Forward Voltage, Through Hole TO-220 Package MSC030SDA120K
Specifications
| Country of Origin | India |
|---|---|
| Brand | Microchip |
| Model | MSC030SDA120K |
| Mount Type | Through Hole |
| Series | MSC0 |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-220 |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | RoHS |
| Maximum Continuous Forward Current If | 30A |
| Peak Reverse Repetitive Voltage Vrrm | 1200V |
| Rectifier Type | Schottky |
| Peak Non-Repetitive Forward Surge Current Ifsm | 75A |
| Maximum Forward Voltage Vf | 1.8V |
Key Features
- The diode features a low forward voltage of 1.8 V for improved efficiency.
- It supports a peak non-repetitive forward surge current of up to 75 A.
- Operating temperature range extends from -55°C to 175°C for robust performance.
- The device is designed for through-hole mounting with a TO-220 package type.
- This Schottky diode demonstrates low leakage current and zero recovery characteristics.
- It is RoHS compliant ensuring environmentally friendly manufacturing.
- Suitable for high switching frequency and power applications.
- Ideal for use as a power parallel diode in industrial and electronic circuits.
Product Description
Microchip MSC030SDA120K is a high-performance Schottky Barrier Diode featuring a peak reverse repetitive voltage of 1200 V and a maximum continuous forward current of 30 A. Packaged in a robust TO-220 through-hole mount, this diode is engineered to offer low forward voltage drop of 1.8 V which enhances power efficiency in high-frequency switching applications.
Designed to operate reliably across a broad temperature range from -55°C to 175°C, this device supports peak non-repetitive forward surge currents up to 75 A. The zero recovery characteristics and low leakage current ensure minimal power loss, making it ideal for industrial power management, power supply rectification, and similar semiconductor applications.
The diode's compliance with RoHS standards makes it suitable for environmentally conscious use in modern electronic manufacturing. Its sturdy TO-220 package provides effective heat dissipation facilitating enhanced durability in demanding operational environments.
Applications include use in power electronics, automotive circuits (non-automotive standard compliant), industrial machinery, and other sectors requiring efficient rectification and switching diode performance.
The diode features a low forward voltage of 1.8 V for improved efficiency. Peak non-repetitive forward surge current up to 75 A supports transient high load conditions. RoHS compliance ensures adherence to environmental regulations.
Extended operating temperature from -55°C to 175°C allows versatile deployment. Through-hole mounting with TO-220 package for easy integration and superior heat dissipation. Zero recovery and low leakage current contribute to power saving and reliability.
Suitable for power parallel diode applications requiring high switching frequency. Constructed by Microchip ensuring trusted semiconductor performance. Explore our extensive range of semiconductor components at EnvMart for all your power and electronic component needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum reverse repetitive voltage rating of this diode is 1200 V.
This model can handle a maximum continuous forward current of 30 A.
The diode features a low forward voltage drop of 1.8 V.
It supports a peak non-repetitive forward surge current of up to 75 A.
The operating temperature range extends from -55°C to 175°C.
This model is designed for through-hole mounting with a TO-220 package type.
Yes, this Schottky diode is RoHS compliant, ensuring it meets environmental standards.
The diode demonstrates zero recovery characteristics, which contribute to minimal power loss during operation.
It is suitable for power electronics, automotive circuits, and industrial machinery requiring efficient rectification and switching performance.
The package type of this diode is TO-220, which facilitates effective heat dissipation.
This diode belongs to the MSC0 series.
The country of origin for this diode is India.
