Texas Instruments Instrumentation Amplifier 0.5 mV Offset 150 kHz 525 μA 16-Pin PDIP INA125PA

Texas Instruments INA125PA instrumentation amplifier is a precision single-channel amplifier designed for accurate differential signal amplification with a low 0.5 mV input offset voltage and a gain bandwidth product of 150 kHz. It comes in a 16-pin PDIP package supporting through-hole mounting and operates efficiently with a low supply current of 525 μA.

This instrumentation amplifier is ideal for applications requiring precise amplification in electrically noisy environments, effectively rejecting common-mode noise signals. It supports a wide supply voltage range from 5 V to 36 V, and operates reliably across a broad temperature spectrum from -55°C to 125°C, suitable for demanding industrial and laboratory environments.

The INA125PA features a common mode rejection ratio of 72 dB and a slew rate of 0.2 V/μs, ensuring stable and accurate signal processing. Its compact dimensions with a height of 4.57 mm and length of 19.3 mm make it versatile for various electronic assemblies.

Typical applications include precision instrumentation systems, medical devices, industrial controls, and data acquisition systems where stable and accurate differential signal amplification is required. The device is designed with robust features to maintain DC precision and gain accuracy even in the presence of large common-mode signals such as AC power line frequency interference.

Single channel, high-precision instrumentation amplifier. Low input offset voltage ensures accurate amplification. Wide supply voltage range from 5 V to 36 V. Efficient low power consumption with 525 μA supply current. Robust temperature tolerance from -55°C to 125°C.

High common mode rejection ratio of 72 dB for noise immunity. Through-hole PDIP 16-pin package for easy PCB integration. Suitable for industrial, laboratory, and medical instrumentation. Explore more Instrumentation Amplifiers and semiconductor solutions at EnvMart.
