Texas Instruments Instrumentation Amplifier 0.5 mV Input Offset 200 kHz 8-Pin MSOP 200 μA INA126EA/250
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 0.97mm |
| Length | 3mm |
| Model | INA126EA/250 |
| Mount Type | Surface |
| Series | INA126 |
| Maximum Operating Temperature | 85°C |
| Package Type | MSOP |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Pin Count | 8 |
| Maximum Supply Voltage | 36V |
| Minimum Supply Voltage | 3V |
| Supply Current | 200μA |
| GBP - Gain Bandwidth Product | 200kHz |
| Vos - Input Offset Voltage | 0.5 mV |
| Slew Rate | 0.4V/μs |
| CMRR - Common Mode Rejection Ratio | 74dB |
Key Features
- This amplifier provides high precision differential amplification with low noise.
- Operates over a wide supply voltage range from 3 V to 36 V.
- Features a common mode rejection ratio of 74 dB to filter out unwanted signals.
- Designed to work in harsh and noisy industrial and laboratory environments.
- Compact surface mount 8-pin MSOP package optimizes PCB space.
- Low supply current of 200 μA enables energy-efficient designs.
- Operating temperature range from -40°C to 85°C for diverse conditions.
- Ideal for signal conditioning in test, measurement, medical, and industrial instrumentation.
Product Description
Texas Instruments INA126EA/250 instrumentation amplifier is a high precision device designed for amplifying differential signals while rejecting common mode interference. It offers a low input offset voltage of 0.5 mV and a gain bandwidth product of 200 kHz, making it suitable for high accuracy instrumentation applications.
The amplifier is housed in an 8-pin MSOP package and operates efficiently with a low supply current of 200 μA over a supply voltage range of 3 V to 36 V. Its robust design supports ambient temperatures from -40°C up to 85°C, ensuring reliable operation in industrial, medical, and laboratory environments.
With a common mode rejection ratio (CMRR) of 74 dB, it effectively suppresses noise and interference from power lines and other environmental sources, ensuring a clean output signal for sensitive applications.
Instrumentation amplifiers like the INA126EA/250 use a classic three operational amplifier configuration that provides high input impedance, low offset and drift, and precise gain setting, meeting the demands of measurement, testing, and control systems.
This device is ideal for applications in industrial process control, medical instrumentation, strain gauge amplification, and wherever precise, low-level signal amplification is required.
High precision with low input offset voltage of 0.5 mV. Wide supply voltage range: 3 V to 36 V. Low supply current consumption of 200 μA. High common mode rejection ratio of 74 dB for noise immunity. Compact 8-pin MSOP surface mount package.
Operating temperature range from -40°C to 85°C. Gain bandwidth product of 200 kHz for fast signal response. Explore further Texas Instruments Instrumentation Amplifiers and related semiconductor components at EnvMart for your precision electronics designs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The input offset voltage of this model is 0.5 mV, ensuring high precision in differential signal amplification.
It operates over a supply voltage range of 3 V to 36 V, making it versatile for various applications.
The common mode rejection ratio (CMRR) is 74 dB, which helps in filtering out unwanted signals and noise.
This model has a gain bandwidth product of 200 kHz, suitable for fast signal response in high accuracy applications.
It can operate within a temperature range of -40°C to 85°C, making it suitable for harsh environments.
The supply current consumption is 200 μA, which allows for energy-efficient designs in electronic applications.
It is housed in a compact 8-pin MSOP surface mount package, optimizing PCB space.
This model has one channel, designed for amplifying differential signals.
The slew rate of this amplifier is 0.4 V/μs, which contributes to its performance in signal processing applications.
It is ideal for applications in industrial process control, medical instrumentation, and strain gauge amplification.
The height of this unit is 0.97 mm, which is part of its compact design.
The length of this model is 3 mm, contributing to its small footprint on PCBs.
