Molex Crimp Connector Housing 20 Contacts 1 Row 3.96 mm Pitch Nylon Straight 9503201
Specifications
| Country of Origin | India |
|---|---|
| Brand | Molex |
| Orientation | Straight |
| Length | 79.15mm |
| Model | 9503201 |
| Width | 6.4mm |
| Housing Material | Nylon |
| Series | 2139 |
| Number of Rows | 1 |
| Pitch | 3.96mm |
| Standards/Approvals | CSA LR19980, UL E29179 |
| Number of Contacts | 20 |
| Connector Gender | Female |
Key Features
- The housing is made of durable nylon material ensuring long-lasting performance.
- Designed for use with 2578 crimp terminals for 22-26 AWG and 2478 crimp terminals for 18-24 AWG wire gauges.
- Features a pitch of 3.96 mm for precise terminal spacing and connections.
- Compact dimensions with length 79.15 mm and width 6.4 mm for space-efficient PCB integration.
- Complies with CSA LR19980 and UL E29179 safety standards.
- Suitable for industrial, electronic assembly, and PCB connector applications.
- Originates from India ensuring quality manufacturing standards.
Product Description
The Molex 9503201 crimp connector housing is a high-quality electronic connector housing designed for reliable and secure connections in various electronics and PCB applications. It features 20 female contacts arranged in a single row, with a pitch distance of 3.96 mm between each contact. The straight body orientation facilitates ease of installation and effective cable management.
Constructed from robust nylon material, this Connector Housing offers excellent durability and resistance to wear, ideal for industrial and commercial electronic assemblies. It is compatible with 2578 crimp terminals suitable for 22-26 AWG wires as well as 2478 crimp terminals for 18-24 AWG wires, among others, ensuring versatility across multiple wiring setups.
Measuring 79.15 mm in length and 6.4 mm in width, the Molex 2139 series housing provides a compact footprint that integrates efficiently within densely populated PCB layouts. It meets industry safety approvals such as CSA LR19980 and UL E29179, assuring users of certified compliance.
This product is manufactured in India and intended for use in electrical components, power connectors, and wire housing applications within electronics manufacturing, industrial automation, and maintenance operations.
The housing is made of durable nylon material ensuring long-lasting performance. Designed for use with 2578 crimp terminals for 22-26 AWG and 2478 crimp terminals for 18-24 AWG wire gauges. Features a pitch of 3.96 mm for precise terminal spacing and connections.
Compact dimensions with length 79.15 mm and width 6.4 mm for space-efficient PCB integration. Complies with CSA LR19980 and UL E29179 safety standards. Suitable for industrial, electronic assembly, and PCB connector applications.
Originates from India ensuring quality manufacturing standards. Explore more in the Electronics & Electricals category at EnvMart for compatible connectors and accessories to complete your projects efficiently.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this connector housing is 3.96 mm, allowing for precise terminal spacing and connections.
The Molex 9503201 features 20 female contacts arranged in a single row.
It is designed for use with 2578 crimp terminals for 22-26 AWG and 2478 crimp terminals for 18-24 AWG wire gauges.
This model measures 79.15 mm in length and 6.4 mm in width, making it compact for PCB integration.
The housing is constructed from durable nylon material, ensuring reliable performance in various applications.
It complies with CSA LR19980 and UL E29179 safety standards, ensuring certified compliance for use in electrical applications.
The Molex 9503201 features a straight body orientation, facilitating ease of installation and effective cable management.
It is suitable for industrial, electronic assembly, and PCB connector applications, providing versatility across multiple wiring setups.
Yes, its compact dimensions and design make it suitable for space-efficient PCB integration.
This connector housing belongs to the 2139 series, which is designed for reliable electronic connections.
This product originates from India, ensuring adherence to quality manufacturing standards.
The connector gender of the Molex 9503201 is female, designed for secure connections with compatible terminals.
