XP Power Isolated DC-DC Converter 10W, 15V DC Input, 500V DC Output, 20mA, Through Hole Mount FS05-15
Specifications
| Country of Origin | United States |
|---|---|
| Voltage | Converters / DC-DC Converters XP Power FS DC/DC Converter, 500V dc/ 20 mA, 15V d |
| Brand | XP Power |
| Efficiency | 85% |
| Length | 57.15mm |
| Model | FS05-15 |
| Gross Weight | 45g |
| Width | 28.5mm |
| Mount Type | Through Hole |
| Series | FS |
| Maximum Operating Temperature | 75°C |
| Minimum Operating Temperature | -25°C |
| MTBF | 840000h |
| Number of outputs | 1 |
| Ripple and Noise | 2% Pk-Pk |
| Maximum Output Power | 10W |
| Maximum Input Voltage | 15V dc |
| Minimum Input Voltage | 0V dc |
| Number of Pins | 8 |
| Output Voltage 1 | 500V dc |
| Output Current 1 | 20mA |
| Isolation Voltage | 2.5kV |
Key Features
- Provides isolated DC to high voltage DC conversion for sensitive electronics.
- Features a through-hole mount design with 8 pins for easy PCB integration.
- Operates efficiently at 85% efficiency with low ripple and noise of 2% peak-to-peak.
- Supports 15V maximum input voltage and outputs 20mA at 500V DC.
- Bears a rugged construction allowing operation from -25°C to 75°C ambient temperature.
- Offers an isolation voltage of 2.5 kV ensuring safety in demanding industrial conditions.
- Measures 57.15mm length and 28.5mm width, weighing approximately 45 grams.
- Mean Time Between Failure (MTBF) is 840000 hours indicating high reliability.
Product Description
XP Power FS05-15 is a high-quality isolated DC-DC converter designed to convert a DC input voltage into a high-voltage DC output suitable for precision electronic applications. This converter provides 10W output power with 15V maximum input and 500V DC output at 20mA, using a through-hole mounting style with an 8-pin configuration for stable PCB assembly.
The device features an 85% efficiency rating and maintains output voltage within ±3% adjustment, with low ripple noise at 2% peak-to-peak, making it well suited for noise-sensitive industrial and laboratory electronics. It offers a robust isolation voltage of 2.5kV, enabling safe usage in environments requiring electrical separation.
Operating over a wide temperature range from -25°C to 75°C, the FS Series converters from XP Power are built for reliability and industrial endurance, with an MTBF of 840,000 hours. The compact package measures 57.15mm by 28.5mm and weighs 45 grams, allowing integration into densely packed control panels and instruments.
This DC-DC converter serves applications such as industrial power supplies, measurement instruments, and other electronic systems requiring stable high-voltage DC outputs. Its through-hole mount design enhances mechanical reliability on printed circuit boards.
Isolated DC to high voltage DC conversion with 10W output power. Through-hole mount for secure PCB installation. High efficiency of 85% reducing power loss and heat. Low output ripple and noise at 2% peak-to-peak. Wide operating temperature range from -25°C to 75°C.
2.5kV isolation voltage ensuring electrical safety. Compact dimensions suitable for dense electronic layouts. High MTBF of 840,000 hours for extended service life.
XP Power is a recognized brand in power conversion, and the FS05-15 model is ideal for various electronic and industrial applications demanding dependable isolated DC-DC power conversion.
Explore more DC/DC Converters and power supply products for industrial and laboratory environments in EnvMart's Electronics & Electricals category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum output power of this DC-DC converter is 10W.
The input voltage range for this model is from 0V to a maximum of 15V DC.
The converter outputs 500V DC at a current of 20mA.
This unit operates with an efficiency rating of 85%.
The isolation voltage of this converter is 2.5kV, ensuring electrical safety in demanding environments.
The dimensions of the FS05-15 are 57.15mm in length and 28.5mm in width, with a weight of approximately 45 grams.
This model operates within a temperature range of -25°C to 75°C.
The FS05-15 has 8 pins for mounting and connection.
The output ripple and noise is specified at 2% peak-to-peak.
This converter is suitable for applications such as industrial power supplies and measurement instruments requiring stable high-voltage DC outputs.
The MTBF for this unit is 840,000 hours, indicating high reliability.
The FS05-15 uses a through-hole mounting style for secure PCB integration.
