| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Height | 5mm |
| Length | 10.9mm |
| Model | ETQP5M |
| Depth | 5mm |
| Packaging | Tape & Reel |
| Series | ETQP5M |
| Maximum Operating Temperature | 150°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Metal Composite |
| Inductance | 1.9μH |
| Standards/Approvals | RoHS |
| Maximum DC Current | 29.8A |
| Pin Count | 2 |
| Maximum DC Resistance | 4.9mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 100kHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Panasonic ETQP5M Shielded Power Choke Coil with Metal Composite Core provides an inductance of 1.9 μH with ±20 % tolerance and a maximum DC current rating of 29.8 A. This surface mount power choke coil is specially designed with a shielded construction to minimize electromagnetic interference and ensure stable operation in automotive and other demanding industrial environments.
The product is engineered with a wirewound and moulded metal composite core that offers excellent bias current tolerance and inductance stability under high vibration and thermal conditions. It supports high heat resistance operation up to 150°C, making it ideal for applications where self-heating occurs.
The low DC resistance of 4.9 mΩ reduces power loss, improving efficiency in power management circuits. The coil meets the rigorous AEC-Q200 automotive standard, ensuring high reliability in safety-critical automotive systems. Its compact form factor of 10.9 mm length by 5 mm height and depth enables it to fit on densely populated PCBs with ease.
Additional notable features include high self-resonant frequency (100 kHz) suitable for switching mode power supplies and availability in tape and reel packaging to facilitate automated assembly in manufacturing processes.
High heat resistance and high reliability under severe automotive conditions. Shielded design reduces audible buzz noise and electromagnetic interference. Compact size and surface mount footprint for efficient PCB layout.
Stable inductance and low losses enable powerful bias current performance. Automotive grade with AEC-Q200 certification for demanding applications.
These features make the Panasonic ETQP5M an excellent choice for automotive, industrial, manufacturing, and power supply design applications requiring robust power inductors with stable and efficient performance.
