Honeywell Technologies Piezoresistive Pressure Sensor Through Hole 8 PIN DIP SSCDANN030PGAA5
Specifications
| Country of Origin | India |
|---|---|
| Accuracy | ±0.25 % |
| Brand | Honeywell |
| Maximum Operating Pressure | 206 kPa |
| Height | 13.75mm |
| Length | 10mm |
| Model | SSCDANN030PGAA5 |
| Sensor Type | Piezoresistive Pressure Sensor |
| Mount Type | Through Hole |
| Series | SSC |
| Maximum Operating Temperature | 85°C |
| Port Type | Single Axial Barbed |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| Pin Count | 8 |
| Maximum Supply Voltage | 5V |
| Minimum Supply Voltage | 3.3V |
| Minimum Operating Pressure | 0psi |
| Maximum Overload Pressure | 413kPa |
Key Features
- The sensor operates with supply voltages from 3.3 V to 5 V.
- It features a maximum operating pressure of 206 kPa and can withstand overloads up to 413 kPa.
- Provides an accuracy of ±0.25%, ensuring reliable measurements.
- Designed with a single axial barbed port and an 8-pin DIP package for easy through-hole mounting.
- Operational temperature range from -40°C to 85°C supports varied environments.
- Incorporates onboard ASIC for full calibration and temperature compensation.
- Detects internal failures and enhances system reliability while promoting extended battery life.
- Fully calibrated sensor optimized for ratiometric analog or digital output applications.
Product Description
Honeywell Technologies SSCDANN030PGAA5 is a piezoresistive pressure sensor designed for integrated electronic systems requiring precise pressure measurement over a specified range. It is housed in a Through Hole 8 PIN Dual Inline Package (DIP) compatible with standard PCB mounting methods.
This sensor operates effectively within a supply voltage range of 3.3 V to 5 V and measures pressures up to a maximum operating pressure of 206 kPa, with a maximum overload capacity of 413 kPa. Its accuracy of ±0.25% enables high precision in critical applications.
The device features a single axial barbed port and compact dimensions of 10 mm length and 13.75 mm height, making it suitable for space-constrained setups. It supports an operating temperature range from -40°C to 85°C, ensuring functionality across diverse industrial, laboratory, HVAC, and manufacturing environments.
An onboard Application Specific Integrated Circuit (ASIC) actively calibrates and compensates for sensor offset, sensitivity, temperature effects, and non-linearity. This advanced design reduces the need for additional calibration by customers and enhances system efficiency and reliability.
The sensor detects most internal faults, including burst sensors, which helps reduce downtime and increases system uptime. Its low power consumption supports extended battery life in portable devices.
Operates from a single power supply of 3.3 V or 5 V. Ratiometric analog or digital output with consistent accuracy. Compact Through Hole DIP package with 8 pins for robust mounting. Temperature compensated for wide temperature ranges.
Designed to improve system reliability and reduce calibration needs. Detects internal failures for preventive maintenance. Suitable for applications in industrial, automotive, laboratory, and HVAC sectors.
This product belongs to the SSC series of sensors by Honeywell, known for its quality and performance. For further design integration, 3D models and schematics are available, aiding engineers in PCB and mechanical design.
Explore more Pressure Sensor ICs from Honeywell and related products in the Electronics & Electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating pressure of this sensor is 206 kPa, with a maximum overload capacity of 413 kPa.
It operates with supply voltages ranging from 3.3 V to 5 V.
The sensor provides an accuracy of ±0.25%, ensuring reliable measurements in various applications.
It supports an operating temperature range from -40°C to 85°C, making it suitable for diverse environments.
This model features a Through Hole mounting type, housed in an 8-pin Dual Inline Package (DIP).
The sensor has dimensions of 10 mm in length and 13.75 mm in height.
It is designed with a single axial barbed port for easy integration into systems.
It incorporates an onboard ASIC for full calibration and temperature compensation, and it detects internal failures to improve reliability and reduce downtime.
Yes, it has low power consumption which supports extended battery life in portable applications.
This sensor is suitable for applications in industrial, automotive, laboratory, and HVAC sectors.
No, the advanced design reduces the need for additional calibration, as it is fully calibrated for use.
