Baumer Mounting Bracket for Use with Mounting Clamp, DIN84, DIN934 Standard Z 119.018

Baumer Z 119.018 mounting bracket is a precision accessory designed specifically for use with mounting clamps in sensor and encoder applications. Manufactured in Germany, this mounting bracket conforms to DIN84 and DIN934 standards ensuring consistent quality and compatibility with industry-standard components.

The bracket is intended for mounting encoder wheels and is supplied with 3 M3 x 12 screws and 3 lock washers that allow the secure attachment of coders with a diameter of 58 mm and centring shoulder diameter of 36 mm. The robust construction and attention to standards make it suitable for challenging industrial environments.

This mounting bracket is ideal for automation, industrial control, sensor installation, and measurement systems in laboratory, manufacturing, and process control settings. It supports precision and reliable positioning of sensors and encoders, vital for accurate data acquisition in automation systems.

The product integrates easily with associated mounting bases such as the Z 119.015 for synchro flange coders and accessories like eccentric devices (Z 119006) for precise fitting. This modular approach enhances flexibility in system assembly and maintenance.

Typical applications for the Baumer mounting bracket include installation in industrial automation systems, sensor accessory setups, and environments requiring precise mechanical fixing of rotary encoders and measurement wheels.

Secure mounting solution for encoder wheels and sensor accessories. Compliant with international mechanical standards (DIN84, DIN934). Includes necessary screws and washers for installation. Manufactured with high durability materials in Germany.

Supports precision installation in industrial automation environments. Explore more sensor accessories and related automation control gear at EnvMart.
