Honeywell Technologies Piezoresistive Pressure Sensor Board 8 DIP, 0.6 kPa Max Operating Pressure, ±0.25% HSCDRRD006MDSA3

Honeywell Technologies HSCDRRD006MDSA3 is a piezoresistive pressure sensor board designed for board-mount applications to measure absolute, gauge, or differential pressures with a maximum operating pressure of 0.6 kPa and an accuracy of ±0.25%. It operates on supply voltages from 3.3V to 5V and is temperature characterised for reliable operation in a wide temperature range between -20°C and +85°C. The sensor features a DIP package with 8 pins and dual radial barbed ports that simplify fluid connections.

This pressure sensor provides a ratiometric analog output or a high-resolution 12-14 bit digital output compatible with I2C or SPI interfaces. On-board ASIC ensures fast output updates up to 2kHz and compensates for temperature variations, correcting offset, sensitivity, and non-linearity.

The HSCDRRD006MDSA3 sensor is ideal for use in industrial and medical environments such as respiratory airflow monitoring, HVAC systems for filter clog detection and VAV control, gas flow instrumentation, chromatography systems, oxygen concentrators, and industrial barometry. Its low power consumption minimizes battery load and heat dissipation, making it suitable for compact device designs.

Operates reliably over temperatures from -20°C to +85°C. Maximum overload pressure of 67.5kPa protects sensor integrity. Complies with ISO 9001 manufacturing standards ensuring quality and consistency. Dual radial barbed ports for versatile fluid connection options.

Compact DIP package with dimensions 13.75mm (height) × 13.3mm (width) × 10mm (length).

This component is an excellent choice for integration in industrial, laboratory, HVAC, and medical instrumentation requiring precise low-pressure measurements. Its adherence to automotive standard ISO 9001 further highlights its manufacturing reliability.
