Eaton Shielded Wirewound Surface Mount Inductor 6.8 μH ±20 %, 13.3 A Idc, Ferrite Core DR127-6R8-R
Specifications
| Country of Origin | China |
|---|---|
| Brand | Eaton |
| Height | 8mm |
| Length | 12.5mm |
| Model | DR127-6R8-R |
| Depth | 12.5mm |
| Packaging | Reel |
| Series | DR |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 6.8μH |
| Standards/Approvals | RoHS |
| Package/Case | 0127 |
| Maximum DC Current | 13.3A |
| Pin Count | 2 |
| Maximum DC Resistance | 11.6mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 100kHz |
| Inductor Construction | Wirewound |
Key Features
- This surface mount inductor features a magnetically shielded wirewound construction for high power density.
- The ferrite core enables efficient energy storage and noise filtering in electronic circuits.
- It has a package/case size of 0127 and is supplied on a reel for surface mounting applications.
- The component offers a maximum operating temperature of 125°C and a minimum operating temperature of -40°C.
- It includes a low maximum DC resistance of 11.6 mΩ for efficient current handling.
- The inductor construction is wirewound with a molded design for reliability and durability.
- It complies with RoHS standards and is made in China.
- Typical applications include use in computers, DVD players, LCD panels, DC-DC converters, and noise filtering circuits.
Product Description
Eaton DR127-6R8-R shielded wirewound surface mount inductor features a ferrite core, 6.8 μH inductance with ±20 % tolerance, and supports a maximum DC current of 13.3 A. This magnetically shielded inductor is designed for efficient energy storage and noise suppression in electronic circuits, complying with RoHS standards and capable of operating in temperatures ranging from -40°C to 125°C.
Its package/case is 0127, designed for surface mount technology with a molded wirewound construction for reliable performance. The component includes a low maximum DC resistance of 11.6 mΩ and a maximum self-resonant frequency of 100 kHz, making it suitable for high-frequency applications.
Common industrial and consumer electronics applications include computers, DVD players, portable devices, LCD panels, and various DC-DC converters such as buck, boost, forward, and resonant converters. The inductor effectively filters noise and stabilizes voltage in power circuits.
This Surface Mount Inductor offers magnetically shielded wirewound construction for enhanced power density. The ferrite core improves energy storage efficiency and noise filtering capability. Supports a maximum DC current of 13.3 A and operates within -40°C to 125°C temperature range.
Low DC resistance of 11.6 mΩ ensures minimal energy loss in circuits. Complies with RoHS standards for environmental and safety regulations. Packaging on reels facilitates automated surface mounting and manufacturing processes.
Ideal for use in consumer electronics, industrial DC-DC converters, and noise suppression applications. Maximum self-resonant frequency of 100 kHz enhances performance in high-frequency environments. Explore the broad Eaton inductors selection available at EnvMart for high-quality electronic components suitable for diverse industrial and commercial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has an inductance value of 6.8 μH with a tolerance of ±20%.
It supports a maximum DC current of 13.3 A.
The inductor operates within a temperature range of -40°C to 125°C.
The maximum DC resistance is 11.6 mΩ, which ensures efficient current handling.
It has a package size of 0127, designed for surface mount applications.
The core material is ferrite, which aids in efficient energy storage and noise filtering.
The maximum self-resonant frequency is 100 kHz, suitable for high-frequency applications.
It is supplied on a reel, facilitating automated surface mounting processes.
Typical applications include computers, DVD players, LCD panels, and DC-DC converters.
Yes, it complies with RoHS standards for environmental and safety regulations.
It features a wirewound construction with a molded design for reliability.
The height of this inductor is 8 mm.
