Panasonic PCB Signal Relay 12V DC Coil 3A SPST DS1E-S-DC12V
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Panasonic |
| Height | 9.4mm |
| Length | 20.2mm |
| Model | DS1E-S-DC12V |
| Width | 9.8mm |
| Mount Type | PCB |
| Contact Material | Gold Plated |
| Series | DS |
| Maximum Operating Temperature | 70°C |
| Contact Configuration | SPST |
| Minimum Operating Temperature | -40°C |
| Switching Current | 3A |
| Terminal type | PCB Terminal |
| Standards/Approvals | RoHS |
| Coil Resistance | 720Ω |
| Coil Voltage | 12V dc |
| Switching DC Voltage | 220V dc |
| Switching AC Voltage | 250V ac |
| Coil Power | 200mW |
| Panasonic PCB Mount Signal Relay, 24V dc Coil, 3A Switching Current, DPDTBrand | Panasonic |
Key Features
- The relay has a coil power consumption of 200mW for energy-efficient operation.
- Supports switching AC voltage up to 250V and DC voltage up to 220V with a maximum current of 3A.
- Constructed with gold-plated contacts for high reliability and resistance to corrosion.
- Compact dimensions with a height of 9.4mm, length of 20.2mm, and width of 9.8mm allow easy PCB integration.
- Designed to operate within a temperature range from -40°C to 70°C, suitable for harsh environments.
- Sealed construction enables automatic washing and ensures long-term durability.
- Ideal for telecommunications, measurement, and computer equipment requiring high performance and resistance to shock and vibration.
Product Description
Panasonic DS1E-S-DC12V is a high-performance PCB Signal Relay equipped with a 12V DC coil and a 3A SPST contact configuration. This relay belongs to the DS series known for its miniature size and highly sensitive operation, making it perfectly suitable for mounting on printed circuit boards in industrial and electronic systems.
With a nominal coil power of 200mW, it supports switching of AC voltages up to 250V and DC voltages up to 220V, facilitating robust electrical switching capabilities. Its gold-plated contacts ensure excellent conductivity and corrosion resistance, improving the relay’s longevity and reliability.
Measuring 9.4mm in height, 20.2mm in length, and 9.8mm in width, the relay’s compact profile simplifies installation on PCBs without occupying excessive space. The relay operates efficiently within a temperature range of -40°C to 70°C, making it suitable for challenging industrial environments where thermal stability is critical.
Sealed construction protects the internals from environmental contaminants, allowing for automatic washing processes during manufacturing. These qualities make the DS1E-S-DC12V relay ideal for telecommunications, computer equipment, and precision measurement devices, where performance under shock, vibration, and harsh conditions is necessary.
The relay features a 12V DC coil voltage. It has a SPST contact configuration. Coil resistance is 720 ohms with a power rating of 200mW. Gold plated contacts ensure durability and reliable switching. The relay supports switching currents of 3A at AC 250V and DC 220V.
Compact dimensions facilitate easy PCB mounting. Operating temperature ranges from -40°C to 70°C. Sealed design allows for automatic washing and resistance to harsh environments. This Panasonic PCB Signal Relay meets RoHS compliance and is manufactured in Japan, guaranteeing quality and industrial reliability.
