Panasonic Surface Signal Relay 12V dc Coil, 1A Switching Current, SPDT Contact Configuration TQ2SA-12V

Panasonic TQ2SA-12V Surface Signal Relay offers a highly reliable, compact electronic switching solution with a 12V DC coil and SPDT contact configuration. This relay is engineered with a low-profile surface-mount design, featuring a flat compact body measuring only 5.6mm in height, 14mm in length, and 9mm in width, making it ideal for dense electronics assemblies.

Equipped with gold plated contacts, it ensures consistent electrical performance and resistance to corrosion. The coil resistance of 1020 ohms and coil power of 140 mW allows for low power consumption during activation. Its high frequency characteristics and low thermal EMF (approx. 2μV) make it particularly suitable for sensitive communication equipment, precision measurement, and quality assurance applications in industrial environments.

The relay operates effectively over a wide temperature range from -40°C to 70°C, supporting switching currents up to 1A, and switching voltages of 125V AC and 110V DC. The PCB terminal mounting provides convenience for surface mounting on printed circuit boards, and the device supports automated SMD insertion processes, enhancing manufacturing efficiency.

This product complies with RoHS standards and is manufactured in Japan, ensuring adherence to environmental and quality standards. The TQ series relay is highly regarded in industrial and laboratory electrical systems requiring reliable signal switching components.

The relay features a flat compact body with a low 6mm profile and surface-mount terminals. It offers high frequency characteristics suitable for sensitive electrical switching applications. Gold plated contact material ensures reliable conductivity and longevity.

Designed for use in communications, measurement, and quality assurance equipment. Coil resistance is 1020 Ω with a coil power consumption of 140 mW. Operates reliably within a temperature range of -40°C to 70°C. Switching voltages up to 125V AC and 110V DC are supported.

PCB terminal type mounting enhances ease of installation and compact circuit design. RoHS compliant construction originating from Japan. Compatible with automated SMD insertion for efficient manufacturing.

EnvMart offers this Panasonic TQ2SA-12V relay for applications in industrial electronics, test and measurement systems, communication technology, and automated manufacturing setups. Browse the Electronics & Electricals > Relays & Contactors section for more options and accessories.
