Texas Instruments Analogue Switch CMOS Single SPDT Multiplexer Demultiplexer 6-Pin SOT-323 TS5A9411DCKR
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1mm |
| Length | 2.15mm |
| Model | TS5A9411DCKR |
| Width | 1.4mm |
| Mount Type | Surface |
| Output type | CMOS/TTL |
| Series | TS5A9411 |
| Configuration | Single SPDT |
| Maximum Operating Temperature | 85°C |
| Package Type | SOT-323 |
| Minimum Operating Temperature | -40°C |
| Pin Count | 6 |
| Number of Elements per Chip | 1 |
| Maximum Supply Voltage | 5.5V |
| Logic Family | CMOS |
| Minimum Supply Voltage | 2.25V |
| Multiplexer/Demultiplexer | Multiplexer, Demultiplexer |
| Maximum On State Resistance | 10Ω |
Key Features
- Operates with a supply voltage range of 2.25V to 5.5V.
- Features low maximum on-state resistance of 10Ω for efficient signal switching.
- Surface mount device available in a compact 6-pin SOT-323 package.
- Operates reliably in temperatures from -40°C to 85°C.
- Provides 1 element per chip configuration for precision switching.
- Compatible with CMOS and TTL output logic types.
- Designed for multiplexer and demultiplexer signal routing applications.
- Compact dimensions of 2.15mm length, 1.4mm width, and 1mm height.
Product Description
Texas Instruments TS5A9411DCKR analogue switch is a high-performance CMOS Single SPDT device, designed as an analogue signal switch and multiplexer/demultiplexer solution. It supports a supply voltage range from 2.25 volts up to a maximum of 5.5 volts, enabling compatibility with low voltage logic systems.
This device features a low maximum on-state resistance of 10 ohms, ensuring minimal signal loss and efficient switching performance. Packaged in a small 6-pin SOT-323 surface mount package with compact dimensions (2.15mm length, 1.4mm width, and 1mm height), it is suitable for space-constrained electronic applications.
TS5A9411DCKR is capable of operating reliably in harsh industrial temperature ranges from -40°C to 85°C, making it useful for a broad range of electronics in automotive, industrial, and consumer equipment. The single SPDT configuration provides one element per chip, supporting CMOS/TTL output logic compatibility for versatile design integration.
This analogue switch simplifies signal routing while minimizing circuit complexity, helping design engineers build multiplexers and demultiplexers efficiently. Operates over 2.25V to 5.5V supply voltage range. Low 10Ω maximum on-state resistance for signal integrity.
Compact surface-mount SOT-323 package with 6 pins. Suitable for industrial temperatures from -40°C to 85°C. Single SPDT switch element for multiplexer applications. Compatible with CMOS and TTL output logic levels. Extensively used in analogue signal switching and routing.
Compact device dimensions for space-limited PCBs.
This Texas Instruments Analogue Switch is ideal for use in electronics, telecommunications, and instrumentation where precise analogue signal management and multiplexing are required.
Explore more semiconductor components in our Electronics & Electricals section at EnvMart for enhanced solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It operates with a supply voltage range from 2.25V to 5.5V.
The maximum on-state resistance is 10Ω, which ensures efficient signal switching.
The dimensions of this model are 2.15mm in length, 1.4mm in width, and 1mm in height.
It operates reliably in temperatures ranging from -40°C to 85°C.
It is designed as a surface mount device.
This model features a single element per chip configuration.
It is compatible with both CMOS and TTL output logic types.
This analogue switch is packaged in a compact SOT-323 format.
It is designed for multiplexer and demultiplexer signal routing applications.
This model belongs to the TS5A9411 series.
The TS5A9411DCKR has a pin count of 6.
The country of origin for this component is India.
