Eaton xEffect FAZ Miniature Circuit Breaker, 1-Pole, 13A, Type C, 240V AC, 48V DC, 10kA Breaking Capacity 278672 FAZ-C13/1N
Specifications
| Country of Origin | India |
|---|---|
| Range | xEffect |
| Brand | Eaton |
| Model | 278672 FAZ-C13/1N |
| Depth | 80mm |
| IP Rating | IP20 |
| Width | 66mm |
| Mount Type | DIN Rail |
| Current Rating | 13A |
| Series | FAZ |
| Terminal type | Screw |
| Breaking Capacity | 10kA |
| Number of Poles | 1 |
| Rated AC Voltage | 240V ac |
| Rated DC Voltage | 48V dc |
| Tripping Characteristics | Type C |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
| Break Time | Instantaneous |
| MCB Module widths | 1P 17.5mm, 2P 35mm and 3P 52.5mm |
| Eaton Bussmann Series 20A Panel Mount Fuse Holder, 1P, 250VBrand | Cooper Bussmann |
Key Features
- Thermal-magnetic tripping mechanism ensures fast short-circuit interruption.
- Designed for DIN rail mounting with a compact 17.5mm module width per pole.
- Supports 240V AC and 48V DC voltage applications.
- Offers 10kA breaking capacity for high electrical safety.
- Equipped with screw terminals and toggle switch reset actuator.
- Finger proof with a trip-free mechanism for enhanced safety.
- Suitable for electrical distribution boards and control circuits.
- Complies with IEC 60947-2 and related industrial standards.
Product Description
Eaton 278672 FAZ-C13/1N miniature circuit breaker is a 1-pole device rated at 13A current with Type C tripping characteristic. It is designed for use in electrical distribution boards and control circuits requiring reliable overload and short-circuit protection. Operating at 240V AC and 48V DC, this breaker provides a breaking capacity of 10kA, ensuring high safety during electrical faults.
The FAZ series features a thermal-magnetic tripping mechanism which enables fast interruption of overloads and short circuits, reducing potential damage to equipment. The 278672 FAZ-C13/1N model mounts easily on standard DIN rails, with a compact module width of 17.5mm per pole, aiding in space-efficient panel design.
The breaker is equipped with screw terminals for secure electrical connections, and a toggle switch for manual reset operation. Its design includes a trip-free mechanism, preventing the breaker from being held in the ON position, and it is finger proof, enhancing operator safety during use.
Compliant with IEC 60947-2 and other relevant standards, the FAZ series from Eaton's xEffect range is built for industrial and commercial applications requiring dependable circuit protection. This series offers modular widths varying by pole count, making it adaptable for single to multiple pole arrangements.
Thermal-magnetic overcurrent protection provides reliable trip response. Compact DIN rail mounting saves panel space. Rated for both AC and DC applications up to 240V AC / 48V DC. High breaking capacity enhances system safety.
Toggle switch for easy manual operation. Trip-free mechanism prevents override of safety feature. Finger proof design reduces operator risk. Clear contact position indication via switch toggle. Meets international standards for low voltage circuit breakers.
Ideal for industrial, commercial, and electrical distribution use cases. Explore a wide range of Eaton electrical components and Miniature Circuit Breakers at EnvMart to ensure optimal safety and performance in your electrical installations.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The breaking capacity of the Eaton FAZ-C13/1N miniature circuit breaker is 10kA, ensuring high electrical safety during faults.
This model supports voltage applications of 240V AC and 48V DC.
The current rating of this miniature circuit breaker is 13A.
It features a thermal-magnetic tripping mechanism that allows for fast interruption of overloads and short circuits.
This model is designed for DIN rail mounting with a compact module width of 17.5mm per pole.
The Eaton FAZ-C13/1N is equipped with screw terminals for secure electrical connections.
The dimensions of the Eaton FAZ-C13/1N are 80mm in depth and 66mm in width.
The IP rating of this circuit breaker is IP20, indicating protection against solid objects greater than 12.5mm.
It includes a trip-free mechanism that prevents the breaker from being held in the ON position and is designed to be finger proof for enhanced safety.
This circuit breaker complies with IEC 60947-2 and related industrial standards.
It is suitable for use in electrical distribution boards and control circuits requiring reliable overload and short-circuit protection.
The reset actuator type for the Eaton FAZ-C13/1N is a toggle switch, allowing for easy manual operation.
