Eaton xEffect FAZ Miniature Circuit Breaker 1-Pole 20A Type C 415V AC 48V DC 10kA Breaking Capacity 102091 FAZ-C20/1-NA

Eaton 102091 FAZ-C20/1-NA Miniature Circuit Breaker is a single-pole, 20 ampere unit featuring a type C tripping characteristic. It operates reliably at rated voltages of 415 volts AC and 48 volts DC and provides a breaking capacity of 10 kiloamperes with instantaneous trip action using a thermal magnetic mechanism. This MCB is part of Eaton's xEffect FAZ series, designed for essential electrical protection in industrial and commercial environments.

Measuring 80mm in height, 17.7mm in width, and 105mm in depth, the compact unit easily fits DIN rail mounting systems with a screw terminal type connection. The front toggle switch acts as a clear visual contact status indicator and ensures safe operation with an IP20 finger protection rating.

The circuit breaker supports current overload and short circuit protection and is particularly well suited for commercial lighting applications due to its type C trip curve that activates between 5 to 10 times the rated current. The rugged design operates efficiently in a broad ambient temperature range from -25°C to +75°C, making it suitable for harsh industrial environments.

With a lightweight construction weighing approximately 121 grams, it imposes minimal load on distribution systems. Installation is simplified by the clip-on DIN rail mount providing a space-saving solution for electrical panel design.

The single-pole design fits compact circuit boards with dimensions of 80mm height, 17.7mm width, and 105mm depth. Supports 20A current rating with thermal magnetic instantaneous tripping mechanism. Rated for 415V AC and 48V DC operation with a 10kA breaking capacity.

Type C tripping characteristics provide suitable protection for commercial lighting systems. DIN rail mount with screw terminal for reliable electrical connection. IP20 finger protection rating ensures enhanced safety. Wide operating temperature range from -25°C to +75°C for industrial use.

Lightweight design at 121 grams minimizes system strain. Part of Eaton's xEffect FAZ series ensuring dependable performance. Clip-on mounting offers space-saving and easy installation.

This MCB is ideal for electrical protection in industrial, commercial, manufacturing, and HVAC installations. Eaton's xEffect series guarantees durability and safety compliance for circuit protection needs. Browse the Electronics & Electricals category on EnvMart for more advanced circuit breakers and protective devices from trusted brands like Eaton.
