IQD 10MHz Oven Controlled Crystal Oscillator DIP 36x27 mm ±1 ppb 3.3V 5-Pin Sinewave Output LFOCXO063815B

Free Delivery in India | Lowest Global Shipping Charges

IQD 10MHz Oven Controlled Crystal Oscillator DIP 36x27 mm ±1 ppb 3.3V 5-Pin Sinewave Output LFOCXO063815B



Category Crystal Oscillator Brand IQD Condition New

Specifications

Country of Origin	India
Brand	IQD
Height	13mm
Length	36.2mm
Model	LFOCXO063815B
Packaging	Bulk
Width	27.2mm
Mount Type	Through Hole
Maximum Operating Temperature	85°C
Output Frequency	10MHz
Package Type	DIP (36 x 27 mm)
Minimum Operating Temperature	-40°C
Standards/Approvals	REACH, RoHS
Pin Count	5
Minimum Supply Voltage	3.3V
Load Capacitance	15pF
Output Level	Sinewave

Key Features

Features ±1 ppb frequency stability ensuring exceptional accuracy.
Compact DIP package measures 36.2 mm length by 27.2 mm width and 13 mm height.
Operates at a fixed supply voltage of 3.3V with a 5-pin through-hole mount.
Produces clean sinewave output ideal for precise timing and frequency control.
Load capacitance is 15 pF optimized for stable performance.
Operating temperature range spans from -40°C to 85°C for reliability in varied environments.
Fully compliant with REACH and RoHS standards for environmental safety.
Designed with an input impedance of at least 100kΩ suitable for controlled circuit integration.

Product Description

IQD LFOCXO063815B is a 10MHz Oven Controlled Crystal Oscillator (OCXO) housed in a DIP package measuring 36.2 x 27.2 x 13 mm. It offers superior frequency stability of ±1 ppb and outputs a sinewave signal, making it ideal for high-precision electronics including laboratory instrumentation, communications equipment, and control systems.

The oscillator operates at a fixed 3.3V supply voltage with a through-hole 5-pin mount design for easy PCB integration. It features a load capacitance of 15pF and a minimum input impedance of 100kΩ, which ensures stable oscillation and signal integrity.

This model is manufactured in accordance with REACH and RoHS compliance, providing assurance for environmentally conscious design requirements. Its high maximum reflow temperature of 260°C allows reliable soldering during assembly processes.

The operating temperature range of -40°C to 85°C guarantees performance across a broad spectrum of industrial and commercial environments, including telecommunications and water treatment instrumentation.

Set includes the IQD LFOCXO063815B oscillator in bulk packaging, suitable for volume assembly use. ±1 ppb frequency stability guarantees precise output frequency control. Compact DIP 36 x 27 mm package dimensions for space-saving PCB layouts.

3.3V fixed supply voltage supports low power consumption designs. Sinewave output delivers clean and stable signal waveforms. Broad temperature range for versatile industrial applications. High input impedance enhances oscillator circuit stability.

Certified RoHS and REACH compliant for restricted substances. Suitable for industrial, laboratory, manufacturing, and communication applications. Explore additional IQD Frequency Products and other oscillators on EnvMart for reliable components designed for professional use.
