STMicroelectronics 2 MB EEPROM, 900 ns, 8-Pin SO-8 Serial-I2C Memory M24M02-DWMN3TP/K

STMicroelectronics M24M02-DWMN3TP/K is a 2 Mbit serial EEPROM automotive grade memory device designed for robust operation in harsh environments with a maximum operating temperature of 125°C. It features a simple Serial-I2C compatible interface that operates at clock frequencies up to 1 MHz, ensuring fast and efficient memory access.

The memory organization is 256k x 8 bits arranged as 1024 pages, each consisting of 256 bytes. This EEPROM uses advanced true EEPROM technology, providing byte-alterable memory with an embedded Error Correction Code (ECC) logic to maintain data integrity over time.

Its surface mount SO-8 package with dimensions of 6.2mm (height) by 5mm (length) and a pin count of 8 allows easy integration into compact assemblies. The device operates from low voltage supplies ranging from 2.5V to a maximum of 5.5V, drawing minimal current of 2 mA typical during operation.

The M24M02-DWMN3TP/K offers a maximum random access time of 900 ns, making it suitable for timing-critical automotive and industrial applications. Its embedded identification page enables secure storage of sensitive parameters, which can also be permanently locked to prevent further modifications.

This EEPROM maintains data retention for up to 100 years and conforms to the AEC-Q100 automotive standard, reflecting its suitability for automotive-grade applications such as engine control, infotainment, and industrial automation.

The device supports a Serial-I2C interface running up to 1 MHz for reliable communication. It offers 2 MB storage organized as 256k x 8 bits with 1024 pages of 256 bytes each. Built to operate across a wide temperature range from -40°C to 125°C for automotive applications.

Consumes low supply current of 2 mA with supply voltage range from 2.5V to 5.5V. Features embedded Error Correction Code logic ensuring data integrity and a 100-year data retention capability. The package dimensions include a height of 6.2mm and length of 5mm, with a pin count of 8.

Includes an additional Identification Page of 256 bytes for device-specific information. Designed to meet the AEC-Q100 automotive standard for quality and reliability.

This product is ideal for use in industrial electronics, automotive control systems, embedded devices, and other applications requiring reliable non-volatile memory with fast access times. Explore similar memory components and other semiconductor solutions in the EnvMart catalog.
