Allegro Microsystems Current Sensor 8-Pin SOIC 20kHz Bandwidth Surface Mount ACS723LLCTR-10AB-T
Specifications
| Country of Origin | India |
|---|---|
| Brand | Allegro Microsystems |
| Height | 1.5mm |
| Length | 4.9mm |
| Model | ACS723LLCTR-10AB-T |
| Mount Type | Surface |
| Bandwidth | 20kHz |
| Series | ACS723 |
| Maximum Operating Temperature | 150°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Offset Voltage | ±15 mV |
| Standards/Approvals | RoHS |
| Pin Count | 8 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 4.5V |
Key Features
- Features a typical offset voltage of ±15 mV.
- Operates with supply voltage ranging from 4.5V to 5.5V.
- Supports high accuracy over a wide temperature range from -40°C to 150°C.
- Provides 3000 Vrms galvanic isolation ensuring electrical safety.
- Compact dimensions measuring 4.9 mm length and 1.5 mm height.
- Utilizes flip-chip technology for integrated current sensing up to 50A.
- Designed with 8 pins in a SOIC package for easy surface mounting.
- RoHS compliant ensuring adherence to environmental standards.
Product Description
Allegro Microsystems ACS723LLCTR-10AB-T is a high precision Current Sensor IC housed in an 8-pin SOIC package designed for surface mount applications. It offers a broad bandwidth of 20kHz and operates between supply voltages of 4.5V and 5.5V, enabling it to perform reliably across various industrial and electronic systems.
This Hall effect current sensor employs advanced flip-chip technology to integrate current sensing for up to 50A, providing reliable and accurate current measurement critical for power and control systems. The device offers galvanic isolation rated at 3000 Vrms, which ensures safety and noise immunity in demanding environments.
The ACS723LLCTR-10AB-T sensor is designed to maintain high accuracy over a wide temperature range from -40°C to 150°C, suitable for automotive and industrial applications. Its compact size with a length of 4.9 mm and a height of 1.5 mm allows for space-efficient PCB layouts.
The sensor features an offset voltage of ±15 mV and operates with minimal typical output error of about 1%, thereby delivering precise current sensing performance. The 8-pin SOIC configuration supports easy surface mounting, making it convenient for automated assembly in manufacturing settings.
Compliance with RoHS standards ensures that the sensor is environmentally friendly and suitable for modern electronics manufacturing. This sensor IC finds applications in electronic components, power and connectors, sensor ICs, industrial automation, power monitoring, and electronic instrumentation.
Features a typical offset voltage of ±15 mV. Operates with supply voltage from 4.5V to 5.5V. Wide operating temperature range: -40°C to 150°C. 3000 Vrms galvanic isolation for safety and noise immunity. Compact 8-pin SOIC package for surface mounting.
Integrated current sensor IC with flip-chip technology supporting up to 50A. High accuracy with typical output error near 1%. RoHS compliant for environmental safety.
This Allegro Microsystems ACS723LLCTR-10AB-T Current Sensor IC is ideal for use in electronic components, power connectors, semiconductor sensor technologies, industrial monitoring, and automotive systems. EnvMart offers this product to support precise current measurement needs in electronic and industrial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The ACS723LLCTR-10AB-T current sensor features a bandwidth of 20kHz, allowing it to accurately measure current over a wide frequency range.
This model operates effectively within a temperature range of -40°C to 150°C, making it suitable for various industrial and automotive applications.
The sensor operates with a supply voltage ranging from 4.5V to 5.5V, ensuring compatibility with many electronic systems.
It can measure current up to 50A, providing reliable performance for power and control systems.
The typical offset voltage for the ACS723LLCTR-10AB-T is ±15 mV, contributing to its accuracy in current sensing applications.
This model has compact dimensions, measuring 4.9 mm in length and 1.5 mm in height, suitable for space-efficient PCB layouts.
The sensor is housed in an 8-pin SOIC package designed for surface mounting, facilitating easy integration into electronic circuits.
Yes, it is RoHS compliant, ensuring adherence to environmental safety standards in electronics manufacturing.
This model employs advanced flip-chip technology for integrated current sensing, enhancing its performance and reliability.
The ACS723LLCTR-10AB-T offers 3000 Vrms galvanic isolation, ensuring electrical safety and noise immunity in demanding environments.
The sensor delivers a minimal typical output error of about 1%, ensuring precise current measurement.
This current sensor is ideal for applications in electronic components, power connectors, industrial automation, and automotive systems.
