Carlo Gavazzi RP1 Series Solid State Relay, 5 A Load, PCB Mount, 530 V AC Load, 32V DC Control RP1A48D5
Specifications
| Country of Origin | China |
|---|---|
| Brand | Carlo Gavazzi |
| Height | 25.4mm |
| Length | 43mm |
| Model | RP1A48D5 |
| Mount Type | PCB |
| Series | RP1 |
| Maximum Operating Temperature | 70°C |
| Capacitance | 8pF |
| Minimum Operating Temperature | -20°C |
| Terminal type | PCB Terminal |
| Switching Function | AC |
| Maximum Load Current | 5A |
| Standards/Approvals | RoHS |
| Maximum Load Voltage | 530V ac |
| Minimum Load Voltage | 20V ac |
| Minimum Control Voltage | 4V dc |
| Maximum Control Voltage | 32V dc |
| Off State Leakage Current | 1mA |
Key Features
- Designed for PCB mounting with compact dimensions.
- Supports maximum load current of 5 amperes for reliable switching.
- Maximum load voltage rating of 530 volts AC.
- Control voltage operates between 4 V DC minimum and 32 V DC maximum.
- Operates with an AC switching function using phase angle control principle.
- Features integral snubber network for enhanced reliability.
- Off state leakage current as low as 1 mA for energy efficiency.
- Wide operating temperature range from -20°C up to 70°C.
Product Description
Carlo Gavazzi RP1A48D5 Solid State Relay is designed for industrial and commercial automation applications requiring reliable AC load switching. This relay is optimized for PCB mounting, offering compact dimensions of 25.4 mm height and 43 mm length, making it suitable for compact electronic designs.
The relay supports up to 5 amperes maximum load current at a high voltage rating of 530 volts AC load. It operates on a DC control voltage range from 4 V to 32 V, making it adaptable to various control circuits and automation controllers.
Its AC switching function uses phase angle control principle with an integral snubber network that protects the device against voltage surges. The off-state leakage current is as low as 1 mA contributing to low standby power losses.
Operating temperature ranges from -20°C to 70°C, ensuring functionality under a variety of environmental conditions for industrial and manufacturing applications. This relay complies with RoHS directives, making it suitable for use in environmentally conscious installations.
Designed for PCB mounting with compact dimensions. Supports maximum load current of 5 amperes for reliable switching. Maximum load voltage rating of 530 volts AC. Control voltage operates between 4 V DC minimum and 32 V DC maximum.
Operates with an AC switching function using phase angle control principle. Features integral snubber network for enhanced reliability. Off state leakage current as low as 1 mA for energy efficiency. Wide operating temperature range from -20°C up to 70°C.
Compact size with 25.4 mm height and 43 mm length dimensions. Compliant with RoHS standards ensuring environmental safety.
This solid state relay is ideal for use in industrial automation, control systems, home automation, HVAC, and manufacturing equipment where precise and reliable AC load control is required.
Explore more Carlo Gavazzi Solid State Relays and related products in the Electronics & Electricals category at EnvMart for a wide range of automation components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum load current for this model is 5 amperes.
This relay has a maximum load voltage rating of 530 volts AC.
It operates on a control voltage range from 4 V DC to 32 V DC.
The dimensions of this relay are 25.4 mm in height and 43 mm in length.
The off-state leakage current is as low as 1 mA, contributing to energy efficiency.
It operates within a temperature range of -20°C to 70°C.
This model is designed for PCB mounting.
It operates with an AC switching function using the phase angle control principle.
Yes, it complies with RoHS standards, ensuring environmental safety.
This solid state relay is suitable for industrial automation, control systems, home automation, HVAC, and manufacturing equipment.
It features PCB terminals for connection.
It includes an integral snubber network to protect against voltage surges, enhancing reliability.
