Carlo Gavazzi RP1 Series Solid State Relay, 3 A Load Current, DIN Rail Mount, 265 V AC Load, 34 V DC Control RP1A23D3M1
Specifications
| Country of Origin | China |
|---|---|
| Brand | Carlo Gavazzi |
| Height | 25.4mm |
| Length | 43mm |
| Model | RP1A23D3M1 |
| Width | 44.5mm |
| Mount Type | DIN Rail |
| Output type | Thyristor |
| Series | RP1 |
| Maximum Operating Temperature | 70°C |
| Contact Configuration | SPST |
| Capacitance | 8pF |
| Minimum Operating Temperature | -20°C |
| Terminal type | Screw |
| Switching Function | Zero Cross Switching |
| Maximum Load Current | 3A |
| Standards/Approvals | EAC, CE |
| Maximum Load Voltage | 265V ac |
| Minimum Load Voltage | 12V ac |
| Minimum Control Voltage | 5V dc |
| Maximum Control Voltage | 34V dc |
| Off State Leakage Current | 1mA |
Key Features
- Supports DIN Rail mounting for easy installation.
- Operates with a control voltage range from 5 V DC to 34 V DC.
- Features zero-cross switching for reduced electrical noise.
- Compact dimensions of 43mm length, 44.5mm width, and 25.4mm height.
- Equipped with screw terminal type for secure connections.
- Thyristor output type ensures efficient switching.
- Off state leakage current is low at 1 mA for energy efficiency.
- Integrated snubber network enhances reliability under inductive loads.
Product Description
Carlo Gavazzi RP1A23D3M1 Solid State Relay belongs to the RP1 series, engineered for phase angle control analog switching of resistive and lightly inductive loads. It provides precise current modulation with a maximum load capacity of 3 A and can operate safely up to 265 V AC load voltage.
Designed with a DIN rail mounting type, this relay simplifies assembly and integration into electrical panels. It features robust screw terminals that guarantee secure wiring and easy maintenance.
The relay operates on a control voltage ranging from 5 V DC minimum to 34 V DC maximum. Its zero cross switching function reduces electrical noise and extends device lifetime. The thyristor output type combined with a built-in snubber network ensures stable switching performance even with slightly inductive loads.
Its compact size, measuring 43 mm in length, 44.5 mm in width, and 25.4 mm in height, enables efficient space utilization in control cabinets. The off-state leakage current remains minimal at 1 mA, improving energy efficiency in automated systems.
Operating effectively in a wide temperature range from -20°C to 70°C, the RP1A23D3M1 relay is suitable for a variety of industrial applications including automation systems, process control, and signal conditioning in harsh environments.
Certified with EAC and CE standards, it complies with industry safety and quality requirements, providing dependable and durable performance. Supports DIN Rail mounting for easy installation. Operates with control voltages from 5 V DC to 34 V DC.
Zero cross switching reduces electrical noise. Compact design with efficient dimensions. Durable screw terminal connections. Thyristor output for precise analog switching. Minimal off-state leakage current of 1 mA. Integral snubber network for load protection.
Wide operating temperature range (-20°C to 70°C). Complies with EAC and CE standards.
This Carlo Gavazzi RP1 Series Solid State Relay is essential for industrial, electrical automation, manufacturing, and process control applications, providing reliable and efficient switching. Explore a wide range of relays and accessories on EnvMart for tailored automation solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum load current for this relay is 3 A.
It operates with a control voltage range from 5 V DC to 34 V DC.
This model can handle a maximum load voltage of 265 V AC.
It supports DIN Rail mounting for easy installation.
The dimensions of this relay are 43 mm in length, 44.5 mm in width, and 25.4 mm in height.
It features a thyristor output type for efficient switching.
Zero cross switching reduces electrical noise and extends the device's lifetime.
The off-state leakage current is low at 1 mA, enhancing energy efficiency.
It operates effectively in a temperature range from -20°C to 70°C.
It is equipped with screw terminal type connections for secure wiring.
This relay is certified with EAC and CE standards, ensuring compliance with industry safety and quality requirements.
It is suitable for industrial applications including automation systems, process control, and signal conditioning.
