Eaton xEffect Miniature Circuit Breaker 2-Pole 5A Type C 415V AC 10 kA Breaking Capacity 278753 FAZ-C5/2
Specifications
| Country of Origin | India |
|---|---|
| Range | xEffect |
| Brand | Eaton |
| Model | 278753 FAZ-C5/2 |
| Depth | 73mm |
| IP Rating | IP20 |
| Width | 85mm |
| Mount Type | DIN Rail |
| Current Rating | 5A |
| Series | xEffect |
| Terminal type | Screw |
| Breaking Capacity | 10kA |
| Number of Poles | 2 |
| Rated AC Voltage | 415V ac |
| Tripping Characteristics | Type C |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
| Break Time | Instantaneous |
Key Features
- Provides reliable overload and short circuit protection for electrical circuits.
- Type C tripping mechanism suited for applications with moderate inrush currents.
- Capable of handling up to 10 kA breaking capacity for high fault currents.
- Features an IP20 touch-proof rating for safety against accidental contact.
- Compact design measuring 85mm width, 36mm length, and 73mm depth for easy DIN rail mounting.
- Equipped with screw terminal connections and toggle switch reset actuator.
- Thermal magnetic tripping mechanism ensures precise and fast response.
- Wide operating temperature range suitable for harsh industrial environments.
Product Description
Eaton 278753 FAZ-C5/2 Miniature Circuit Breaker is a 2-pole device designed for effective circuit protection with a 5A current rating and type C tripping characteristics. It operates at a rated AC voltage of 415V and has a breaking capacity of 10 kA, making it suitable for industrial, commercial, and residential applications requiring reliable overcurrent protection.
This circuit breaker features a thermal magnetic tripping mechanism that enables rapid response to overloads and short circuits, preventing damage to connected equipment. Its compact dimensions (85mm width x 36mm length x 73mm depth) and DIN rail mounting make it suitable for installation in control panels and crowded electrical enclosures.
The device includes a colour-coded contact position indicator for quick status checks and captive screws which cannot be lost during installation. The IP20 rating confirms protection against accidental contact with live parts, ensuring user safety during operation and maintenance.
Owing to its type C trip curve, it is designed for applications with moderate inrush current such as fluorescent lighting, control circuits, and motor loads. The toggle switch actuator facilitates easy manual reset of the breaker after tripping.
Eaton's xEffect series offers dependable electrical protection in a compact form factor ideal for controlling electrical distribution systems in a variety of industrial, commercial, and residential setups.
Provides reliable overload and short circuit protection for electrical circuits. Type C tripping mechanism suited for applications with moderate inrush currents. Capable of handling up to 10 kA breaking capacity for high fault currents.
Features an IP20 touch-proof rating for safety against accidental contact. Compact design measuring 85mm width, 36mm length, and 73mm depth for easy DIN rail mounting. Equipped with screw terminal connections and toggle switch reset actuator.
Thermal magnetic tripping mechanism ensures precise and fast response. Wide operating temperature range suitable for harsh industrial environments. Explore the comprehensive range of Eaton circuit protection devices and related electrical components on EnvMart for your industrial and commercial electrical protection needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 5A, making it suitable for various electrical applications requiring this level of protection.
It is capable of handling a breaking capacity of 10 kA, which allows it to manage high fault currents effectively.
This circuit breaker features a thermal magnetic tripping mechanism that ensures rapid response to overloads and short circuits.
The rated AC voltage for this model is 415V, making it suitable for various industrial and commercial applications.
The dimensions of this unit are 85mm in width, 36mm in length, and 73mm in depth, allowing for compact installation.
It is designed for DIN rail mounting, which facilitates easy installation in control panels and crowded electrical enclosures.
The circuit breaker has an IP20 rating, providing protection against accidental contact with live parts.
It is equipped with a toggle switch reset actuator, allowing for easy manual reset after tripping.
The Type C tripping mechanism is suited for applications with moderate inrush currents, such as fluorescent lighting and motor loads.
It features screw terminal connections, which provide a secure and reliable connection for electrical wiring.
The country of origin for this model is India, indicating its manufacturing location.
This model is part of the xEffect series, which includes various circuit protection devices designed for effective electrical safety.
