RS PRO Surface Mount Battery Holder for CR1225 Battery 2 Cells PCB Mount CR1225

RS PRO CR1225 Surface Mount Battery Holder is designed to securely hold two CR1225 button cells in electronic assemblies. This battery holder is made from high-quality Polybutylene Terephthalate (PBT) material reinforced with 30% glass filling to provide excellent mechanical strength and thermal stability. The surface mount design enables easy assembly on printed circuit boards (PCB), making it suitable for compact electronic devices.

The holder supports a voltage rating of 500V AC/DC and a continuous current rating of 2A, ensuring dependable electrical performance in various applications. The contacts are manufactured from phosphor bronze, plated with 0.2mm thick tin over nickel, providing excellent conductivity and corrosion resistance. It offers an insulation resistance of 500 megaohms, ensuring safety in sensitive electronic circuits, and a maximum contact resistance of 30 milliohms for minimal power loss.

Operating over a wide temperature range from -55°C to 85°C, this battery holder is ideal for industrial, electronic manufacturing, and laboratory equipment environments. Its compact size with dimensions of 15mm width, 12.5mm diameter, and 8mm height allows integration into small form factor designs.

The product is designed for surface mounting on PCBs, making it convenient for automatic assembly and ensuring stable mechanical and electrical contact. This RS PRO series holder is manufactured in China with robust standards compliance and UL 94V0 approved insulation characteristics.

Compatible with CR1225 battery size and holds 2 cells securely. Made from Polybutylene Terephthalate (PBT) with 30% glass-filled for durability. Surface mount termination type designed for PCB mounting applications. Voltage rating of 500V AC/DC and current rating up to 2A for reliable power delivery.

Operating temperature range from -55°C to 85°C ensures performance under varied environments. Contacts made of phosphor bronze, 0.2mm thick tin plated over nickel for excellent conductivity. High insulation resistance of 500 megaohms and low contact resistance of 30 milliohms maximum.

Compact dimensions: 15mm width, 12.5mm diameter, and 8mm height for space-efficient design.

This battery holder is suitable for use in industrial electronics, laboratory instruments, medical devices, instrumentation, control equipment, and other electronics assemblies requiring efficient and reliable battery mounting solutions. For further options on Battery Holders and related accessories, browse through EnvMart’s comprehensive Electronics & Electrical category.
