Vishay VLMY30 Yellow CoB LED PLCC-2 Package 2.4mm Optical Source Diameter 15mA Forward Current VLMY30

Vishay VLMY30 Yellow CoB LED model VLMY30 is a surface mount device (SMD) LED designed for precise yellow light emission with a luminous intensity of 22.4mcd. Housed in a PLCC-2 package, this LED integrates a lead frame embedded in a white thermoplastic material and a reflector filled with clear epoxy for optimal light output.

The LED features a maximum forward current of 15mA with a forward voltage of 2.2V, enabling efficient low current operation suitable for a wide range of electronic and lighting applications. It has an optical source diameter of 2.4mm and compact dimensions of 3.5mm length and 2.8mm width, making it ideal for automated placement on PCBs.

Its ±60° viewing angle provides effective light dispersion, while compliance with automotive standard AEC-Q101 ensures high reliability in demanding applications. This component has been tested and approved according to ICE, J-STD-020, CECC 00802, and EIA standards.

Features a luminous intensity of 22.4mcd for clear yellow light emission. Maximum forward current rating of 15mA ensures efficient operation. Viewing angle is ±60 degrees to provide good illumination dispersion. Forward voltage is 2.2V suitable for low voltage applications.

Compact LED with dimensions 3.5mm length and 2.8mm width. Complies with automotive standard AEC-Q101 ensuring reliability. Constructed with a white thermoplast embedded lead frame and a clear epoxy-filled reflector. Compatible with automatic placement equipment for easy assembly.

Meets multiple approvals including ICE, J-STD-020, CECC 00802, and EIA standards.

This Vishay CoB LED is widely used in industrial, commercial, automotive, and electronic component manufacturing to provide bright, reliable yellow indication or illumination in a compact form. It is suited for applications requiring consistent brightness and industry-standard quality certifications.
