Omron Illuminated Push Button Switch Panel Mount DPDT 30V dc 250V AC 16 mm Cutout A165L-TRM-24D-2

Omron A165L-TRM-24D-2 illuminated push button switch is a reliable and compact panel mount device designed for industrial electrical and automation applications. It features a 16 mm cutout panel size and a red illuminated actuator enabling clear operator feedback in various control and signaling setups. The DPDT contact configuration provides dual switching with double throw capability, suitable for both control and signal circuits.

This switch supports contact voltages of up to 30 V dc and 250 V AC, making it versatile for different electrical environments. Its PCB pin terminal design ensures compatibility with printed circuit board assemblies for streamlined installation.

Rated IP65, the device is sealed against dust ingress and water jets, suitable for harsh industrial environments. Operating reliably in the temperature range from -10°C to 55°C, it maintains performance stability in diverse climates.

Designed according to international safety and quality standards including EN60947-5-1, UL cUL, CCC, and TÜV certifications, it fulfills rigorous global compliance requirements.

The compact form factor with a width of 16 mm and height of 28.5 mm allows for efficient use of panel space in control panels and industrial machinery. This switch is part of Omron's A16 series known for modular construction and ease of assembly.

The illuminated red actuator enhances visual status indication in control applications. Panel mounting via a 16 mm cutout ensures secure and ergonomic installation. DPDT switch contact arrangement allows complex control logic use cases.

PCB pins facilitate quick and reliable electrical connections. The IP65 rating protects against dust and water, extending switch longevity in industrial environments. Wide operating temperature rating ensures resilience under varied conditions.

Compliance with multiple safety standards assures product reliability and user safety. Compact height and width suit modern industrial panel designs. Modular and detachable switch unit design simplifies maintenance and replacement.

Ideal for industrial automation, electrical control systems, manufacturing, and HVAC control panels, the Omron A165L-TRM-24D-2 switch provides dependable performance in demanding settings. Explore similar Push Button Switches and components in the Electronics & Electricals section on EnvMart for your application needs.
