Hongfa Europe GMBH Surface Mount Force Guided Relay 24V DC Coil Voltage 1-Pole DPDT HFA4/24-2H2DTGF
Specifications
| Country of Origin | China |
|---|---|
| Brand | Hongfa Europe GMBH |
| Height | 24mm |
| Length | 40mm |
| Model | HFA4/24-2H2DTGF |
| Depth | 13mm |
| Mount Type | Surface |
| Contact Material | Silver Alloy |
| Series | HFA4 |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -40°C |
| Terminal type | PCB Terminal |
| Number of Poles | 1 |
| Coil Resistance | 1.6kΩ |
| Coil Power | 360mW |
| Outline Dimensions | (40.0 x 13.0 x 24.0) mm |
| Isolation Coil To Contact | 10kV |
| Multi contact arrangements | 2NO+2NC |
| Low input power | 360mW |
| High insulation capability | 10kV surge voltage between input and output |
Key Features
- Features surface mount type suitable for PCB integration.
- Contact configuration is DPDT with silver alloy contact material.
- Offers high insulation with a 10kV surge voltage between coil and contacts.
- Operates efficiently with low coil power consumption of 360mW.
- Supports temperature range from -40°C to 85°C for diverse environments.
- Compact outline dimensions measuring 40 x 13 x 24 mm (L x D x H).
- Each relay includes 2NO+2NC forcibly guided contacts rated at 6A switching capability.
- Coil resistance is 1.6 kΩ ensuring stable operation.
Product Description
Hongfa Europe GMBH HFA4/24-2H2DTGF surface mount force guided relay features a 24V DC coil voltage and a 1-pole DPDT contact configuration, optimized for industrial and automation control applications. This relay ensures precise switching with forcibly guided contacts rated for 6A switching capacity, making it suitable for safety and monitoring circuits.
Its low coil power consumption of 360mW and coil resistance of 1.6kΩ enable energy-efficient operation. The relay operates reliably in harsh environments within a temperature range from -40°C to 85°C. The silver alloy contact material provides excellent conductivity and durability for long service life.
The relay boasts high insulation capability with a 10kV surge voltage rating between coil and contacts, ensuring protection against electrical noise and transients. Its compact footprint, measuring 40mm length, 13mm depth, and 24mm height, is ideal for space-constrained PCB layouts. The PCB terminal type aids in easy installation and soldering.
Designed to comply with environmental standards, this product is RoHS certified, promoting eco-friendly use. It is manufactured in China under the HFA4 series, combining high performance with reliability.
Surface mount with PCB terminals for secure attachment. DPDT contact configuration with forcibly guided contacts. High insulation and surge voltage withstand capacity. Low coil power consumption enhances energy savings. Wide operating temperature suitable for industrial conditions.
Compact and efficient for space-limited designs. Silver alloy contact material ensures reliable conductivity. Multi contact arrangements (2NO+2NC) enhance versatility. Suitable for automation, control, and safety relay applications.
Environmentally friendly construction with RoHS compliance. Explore a wide selection of relays and Force Guided Relays in the Electronics & Electricals category at EnvMart, ideal for industrial, automation, and control system requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay operates with a coil voltage of 24V DC.
It features a DPDT (Double Pole Double Throw) contact configuration.
The maximum operating temperature is 85°C.
The coil power consumption is 360mW, allowing for energy-efficient operation.
It has a high insulation capability with a surge voltage rating of 10kV between the coil and contacts.
The relay measures 40mm in length, 13mm in depth, and 24mm in height.
This model uses PCB terminals for secure attachment and easy soldering.
The coil resistance is 1.6 kΩ, ensuring stable operation.
The contact material is silver alloy, which provides excellent conductivity.
It includes multi contact arrangements of 2NO (Normally Open) and 2NC (Normally Closed) forcibly guided contacts.
The minimum operating temperature is -40°C, making it suitable for harsh environments.
Yes, this relay is RoHS certified, promoting eco-friendly use.
