EOZ DJET Series Momentary Push Button Switch, Panel Mount, SPST, IP67, 110V AC 17.17252.30



Category Push Button Switch Brand EOZ Condition New

Specifications

Country of Origin	France
Brand	EOZ
IP Rating	IP67
Mount Type	Panel
Series	DJET
Maximum Operating Temperature	85°C
Contact Configuration	SPST
Switch Configuration	CO
Minimum Operating Temperature	-40°C
Panel Cutout Size	10 mm
Terminal type	Solder
Standards/Approvals	RoHS
Switch Operation	Momentary
Actuator Style	Cylinder
Switch Contact Current	2.5A
Contact AC Voltage	110V ac
EOZ Push Button Switch, Momentary, Panel Mount, SPSTBrand	EOZ

Key Features

This switch operates momentarily, making contact only while held.
It features a 10 mm panel cutout size for mounting.
The contact material is gold for superior corrosion resistance.
The switch body has a matte black finish for durability.
Rated to withstand temperatures from -40°C to 85°C.
Offers protection against dust and temporary liquid immersion with an IP67 rating.
Designed with a cylindrical actuator style for ease of use.
It supports a maximum switch contact current of 2.5A AC.

Product Description

EOZ 17.17252.30 is a high-quality momentary push button switch from the DJET Series designed for robust industrial and commercial applications. It features a panel mount design with a 10 mm cutout, ideally suited for control panels and instrumentation requiring reliable switch operation.

The switch operates with a single pole single throw (SPST) configuration, delivering control over one circuit momentarily while the button is pressed. Upon release, the switch returns to its default off position.

Constructed with gold contacts, this switch ensures excellent corrosion resistance for long-term electrical reliability. The matte black finish offers a professional appearance and enhanced resistance to environmental wear. The IP67 ingress protection rating certifies the switch is completely dust-tight and can withstand temporary immersion in water, making it suitable for harsh environments including outdoor telecommunications, military, and aviation equipment.

This push button switch is designed with a cylindrical actuator providing responsive tactile feedback. It supports a contact AC voltage of 110V and a switch contact current of up to 2.5A AC. Operating temperature ranges from -40°C to 85°C, allowing operation in extreme conditions.

The DJET Series Push Button Switches find applications in industrial automation, power supplies, and medical equipment where precision and durable switch performance are mandatory. Installation is straightforward by placing the switch into the panel opening and securing it with a fixing nut for stable mounting.

This switch operates momentarily, making contact only while held. It features a 10 mm panel cutout size for mounting. The contact material is gold for superior corrosion resistance. The switch body has a matte black finish for durability.

Rated to withstand temperatures from -40°C to 85°C. Offers protection against dust and temporary liquid immersion with an IP67 rating. Designed with a cylindrical actuator style for ease of use. It supports a maximum switch contact current of 2.5A AC.

Complies with RoHS environmental standards. Manufactured in France ensuring quality and reliability. Explore EOZ's extensive range of switches and related electrical components at EnvMart for dependable industrial and automation solutions.
