Littelfuse Surface Mount 3-Pin TRIAC, 25A Rated Current, 800 V Peak Reverse Voltage, Gate Trigger 2.5 V Q8025NH6RP
Specifications
| Country of Origin | India |
|---|---|
| Brand | Littelfuse |
| Height | 4.78mm |
| Length | 10.67mm |
| Model | Q8025NH6RP |
| Mount Type | Surface |
| Configuration | Single |
| Maximum Operating Temperature | 125°C |
| Package Type | TO-263 |
| Minimum Operating Temperature | -40°C |
| Pin Count | 3 |
| Rated Average On-State Current Irms | 25A |
| Repetitive Peak Reverse Voltage VDRM | 800V |
| Surge Current Rating | 250A |
| Maximum Gate Trigger Current Igt | 80mA |
| Maximum Holding Current Ih | 100mA |
| Maximum Gate Trigger Voltage Vgt | 2.5V |
| Peak On-State Voltage | 1.8V |
| Repetitive Peak Off-State Current | 0.01mA |
| Peak Gate Power Dissipation | 0.5W |
Key Features
- Designed for surface mounting with a TO-263 package type.
- Maximum gate trigger voltage is 2.5 volts ensuring efficient triggering.
- Capable of handling a surge current rating of 250 amperes.
- Operates reliably between -40°C and 125°C.
- Features a repetitive peak off-state current of 0.01 mA minimizing leakage.
- Compact dimensions include length of 10.67 mm and height of 4.78 mm.
- Suitable for alternating current circuit switching and control in industrial and electronic applications.
- Non-automotive standard component without specific certifications.
Product Description
The Littelfuse Q8025NH6RP is a high-performance 3-pin TRIAC designed for surface mounting applications. This discrete semiconductor device supports a rated average on-state current of 25 amperes and provides a repetitive peak reverse voltage of 800 volts, making it suitable for switching and control of alternating current circuits. It features a TO-263 package type optimized for ease of assembly on printed circuit boards.
This TRIAC boasts a maximum gate trigger voltage of 2.5 volts and maximum gate trigger current of 80 mA, ensuring reliable and precise triggering under diverse electrical conditions. The device supports a peak on-state voltage of 1.8 volts and a maximum holding current of 100 mA.
Engineered to operate within a temperature range of -40°C to 125°C, it remains stable and efficient in demanding industrial and commercial environments. The device dimensions are compact with a length of 10.67 mm and height of 4.78 mm, making it suitable for dense PCB layouts.
The surge current rating of 250 amperes allows this TRIAC to withstand transient conditions without damage. It handles repetitive peak off-state current at very low leakage levels (0.01 mA), maintaining circuit integrity. Although it does not conform to automotive standards or specific approvals, it is a robust choice for industrial, laboratory, HVAC, manufacturing, and general electronic applications requiring reliable AC switching.
Designed for surface mounting with TO-263 package. Rated for 25 A on-state current and 800 V peak reverse voltage. Gate trigger voltage is 2.5 V with a trigger current maximum of 80 mA. Operates stably in temperatures ranging from -40°C to 125°C.
Compact size allows for efficient PCB integration. Suitable for industrial AC switching and control applications. Supports surge currents up to 250 A for transient conditions. Low off-state leakage current preserves circuit performance.
This product is an excellent selection for electronic manufacturing, industrial automation, and semiconductor components categories. For more options or compatible devices, please explore the TRIAC section under Semiconductor components at EnvMart.
Explore more products in our TRIACs category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The rated average on-state current for this model is 25 amperes.
The maximum gate trigger voltage for this TRIAC is 2.5 volts.
The dimensions of this model are 10.67 mm in length and 4.78 mm in height.
The surge current rating for this TRIAC is 250 amperes.
It operates reliably within a temperature range of -40°C to 125°C.
The maximum holding current for this TRIAC is 100 mA.
This model uses a TO-263 package type, designed for surface mounting.
The peak on-state voltage for this TRIAC is 1.8 volts.
The maximum gate trigger current is 80 mA.
The repetitive peak off-state current is 0.01 mA, which minimizes leakage.
This TRIAC is suitable for alternating current circuit switching and control in industrial and electronic applications.
