Eaton Shielded Wirewound Surface Mount Inductor with Ferrite Core 2.2μH ±20% 5.52A IDC 0703 DR73-2R2-R

Eaton DR73-2R2-R is a shielded wirewound Surface Mount Inductor featuring a durable ferrite core and a compact 0703 package size. It provides an inductance of 2.2μH with a tolerance of ±20% and supports a maximum DC current of 5.52A, making it suitable for efficient power conversion and noise suppression in electronic circuits.

This inductor is designed for high power density and reliability with its magnetic shielding that minimizes electromagnetic interference and a maximum operating temperature of 125°C for stable operation across environments. The low maximum DC resistance of 16.5mΩ helps reduce energy losses, improving overall circuit efficiency.

Applications include computers, portable devices, LCD panels, and various DC-DC converter topologies such as buck, boost, forward, and resonant converters. These inductors are molded and feature two pins for secure surface mounting, ensuring good mechanical and electrical stability.

The product complies with RoHS standards, ensuring environmentally friendly production and safety compliance. Manufactured in China, these inductors come packaged on reels for efficient assembly in automated production lines.

Provides magnetic shielding to reduce electromagnetic interference. Constructed with a ferrite core for stable inductance across temperatures. Surface mount 0703 package dimensions 7.6mm length by 3.55mm height. Rated for a maximum operating temperature of 125°C for reliable performance.

Features ±20% inductance tolerance suitable for various power electronics. Maximum DC resistance of 16.5mΩ ensures low power dissipation. Designed for use in DC-DC converters, noise filtering, and resonant converters. Compliant with RoHS standards for environmental safety and quality.
