Eaton Shielded Surface Mount Inductor with Ferrite Core 68 μH ±20% 4.44 A DC Current DR127-680-R
Specifications
| Country of Origin | China |
|---|---|
| Brand | Eaton |
| Height | 8mm |
| Length | 12.5mm |
| Model | DR127-680-R |
| Depth | 12.5mm |
| Packaging | Reel |
| Series | DR |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 68μH |
| Standards/Approvals | RoHS |
| Package/Case | 0127 |
| Maximum DC Current | 4.44A |
| Pin Count | 2 |
| Maximum DC Resistance | 105mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 100kHz |
| Inductor Construction | Wirewound |
Key Features
- Magnetically shielded design reduces electromagnetic interference.
- Wirewound construction ensures high power density and efficiency.
- Compact 0127 package case with 2 pins for surface mounting.
- Inductance tolerance of ±20% for reliable circuit performance.
- Operates within temperature range -40°C to 125°C.
- Ferrite core material contributes to optimized magnetic properties.
- Maximum DC resistance of 105 mΩ minimizes power loss.
- Suitable for DC-DC converters, noise filtering, and various power electronics.
Product Description
Eaton DR127-680-R shielded surface mount inductor is engineered with a high-quality ferrite core and wirewound construction, delivering 68 μH inductance with ±20% tolerance and a maximum DC current of 4.44 A. This inductor’s magnetically shielded design effectively minimizes electromagnetic emissions, making it suitable for sensitive electronic circuits.
Encased in a compact 0127 package with dimensions 12.5 mm length, 8 mm height, and 12.5 mm depth, it supports surface mount technology enabling efficient PCB assembly. The termination style is surface mount with a 2-pin configuration, designed for reel packaging facilitating high volume automated production.
Performance parameters include a maximum operating temperature of 125°C and a minimum of -40°C, along with a maximum DC resistance of 105 mΩ that ensures low power dissipation. The inductor has a high self-resonant frequency at 100 kHz, supporting various power electronic applications such as DC-DC converters, buck, boost, forward and resonant converters, noise filtering, and chokes.
This product complies with RoHS standards, ensuring environmentally friendly manufacturing. The Eaton DR series is known for its reliability and high efficiency in industrial, computing, consumer electronics, and telecommunications applications.
Manufactured in China, the Eaton DR127-680-R brings together compact size, high performance, and durability for demanding electronics designs. Magnetically shielded design reduces electromagnetic interference. Wirewound construction ensures high power density and efficiency.
Compact 0127 package case with 2 pins for surface mounting. Inductance tolerance of ±20% for reliable circuit performance. Operates within temperature range -40°C to 125°C. Ferrite core material contributes to optimized magnetic properties.
Maximum DC resistance of 105 mΩ minimizes power loss. Suitable for DC-DC converters, noise filtering, and various power electronics. Complies with RoHS standards for environmental safety. High self-resonant frequency of 100 kHz.
Explore more industrial and electronic components like Surface Mount Inductors on EnvMart to find reliable, high-quality products tailored for your technical needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Eaton DR127-680-R has an inductance value of 68 μH with an inductance tolerance of ±20%.
This model can handle a maximum DC current of 4.44 A.
The dimensions of the 0127 package case are 12.5 mm in length, 8 mm in height, and 12.5 mm in depth.
The maximum operating temperature for the Eaton DR127-680-R is 125°C.
The inductor uses a ferrite core material, which contributes to optimized magnetic properties.
The maximum DC resistance is 105 mΩ, which helps minimize power loss.
This inductor has a high self-resonant frequency of 100 kHz.
The termination style of the Eaton DR127-680-R is surface mount with a 2-pin configuration.
It operates within a temperature range of -40°C to 125°C.
This inductor is suitable for DC-DC converters, noise filtering, and various power electronics applications.
This model complies with RoHS standards, ensuring environmentally friendly manufacturing.
The Eaton DR127-680-R is manufactured in China.
