Eaton Shielded Wirewound Surface Mount Inductor with Ferrite Core 15 μH ±20 % 5.69 A Idc DR125-150-R

Eaton DR125-150-R shielded wirewound surface mount inductor features a ferrite core, delivering 15 μH inductance with ±20 % tolerance and supporting a maximum DC current of 5.69 A. This 0125 package device measures 12.5 mm in length and 6 mm in height, optimized for surface mount PCB applications.

The inductor is molded with magnetic shielding to reduce electromagnetic interference allowing efficient operation in sensitive electronic environments. It operates reliably between -40°C and 125°C, suitable for industrial, commercial electronics, and power conversion uses.

Its low maximum DC resistance of 29.8 mΩ ensures efficiency while handling currents with minimal loss. The device exhibits a maximum self-resonant frequency of 100 kHz, ideal for filtering and noise suppression in computer, DVD player, LCD panel, and DC-DC converter applications including buck, boost, forward, and resonant converters.

Manufactured in China, this inductor conforms to RoHS standards. Package includes a reel for ease of automated placement during electronics manufacturing. This inductor features a ferrite core for enhanced magnetic performance.

Designed with a compact 0125 package case measuring 12.5 mm length and 6 mm height. Rated for a maximum operating temperature of 125°C ensuring reliable performance under high temperatures. Features magnetic shielding to minimize electromagnetic interference in electronic circuits.

Suitable for surface mount applications with two pins and molded construction. Maximum DC resistance is 29.8 mΩ minimizing power losses in high current applications. Inductance tolerance is ±20 % for predictable inductive behavior.

Operating temperature range spans from -40°C to 125°C suitable for diverse environments. Maximum self-resonant frequency is 100 kHz, supporting various frequency ranges in circuitry.

This product is ideal for use in industrial electronic manufacturing, power conversion circuits, noise filtering, and electronic signal conditioning. Browse more Surface Mount Inductors at EnvMart for a broad selection of electronic passive components with quality and reliability.
