Infineon 2 Axis Surface Inclinometer Digital Sensor 3 V to 5.5 V 8-Pin DSO TLE5012BE1000XUMA1
Specifications
| Country of Origin | India |
|---|---|
| Brand | Infineon |
| Height | 1.45mm |
| Length | 5mm |
| Model | TLE5012BE1000XUMA1 |
| Technology | Digital |
| Sensor Type | Inclinometer Sensors |
| Width | 4mm |
| Mount Type | Surface |
| Series | TLE5012B |
| Maximum Operating Temperature | 150°C |
| Package Type | DSO |
| Minimum Operating Temperature | -40°C |
| Number of axis | 2 |
| Interface Type | IIF |
| Pin Count | 8 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 3V |
| Supply Current | 16mA |
| Maximum Frequency Response | 4.3MHz |
| Minimum Frequency Response | 3.8MHz |
Key Features
- Measures 360° angle orientation using integrated Giant Magneto Resistance sensor technology.
- Provides highly accurate sine and cosine angle measurements with 15-bit resolution.
- Supports bi-directional synchronous serial communication compatible with SPI.
- Operates over a wide temperature range from -40°C to 150°C.
- Compact surface mount design with dimensions 5 mm length, 4 mm width, and 1.45 mm height.
- Low supply current of 16 mA ensures efficient operation.
- Automotive AEC-Q100 standard compliant for robustness in automotive environments.
- Includes autocalibration algorithm for stable long-term performance.
Product Description
The Infineon TLE5012BE1000XUMA1 is a 2 axis surface inclinometer sensor designed for precise angular position detection in industrial and automotive applications. This digital inclinometer sensor utilizes integrated Giant Magneto Resistance (iGMR) elements to measure sine and cosine components of magnetic field orientation, enabling full 360° angle detection with high precision.
Operating on a supply voltage range from 3 V to 5.5 V, the sensor is packaged in a compact 8-pin DSO form factor measuring 5 mm by 4 mm by 1.45 mm, facilitating easy surface mount integration into circuit boards. Its operating temperature spans from -40°C to 150°C, making it suitable for harsh operating conditions often found in automotive and industrial environments.
The sensor communicates via a bi-directional synchronous serial interface (IIF) compatible with SPI standards, transmitting absolute angle values with a resolution of 0.01°. Additionally, it supports pulse-width modulation (PWM) output for flexible signal conditioning. The onboard autocalibration algorithm enhances measurement stability and accuracy over long-term use.
This inclinometer features low supply current consumption of 16 mA, supporting efficient power management in embedded systems. It is compliant with the automotive quality standard AEC-Q100, ensuring reliability in demanding vehicular applications.
Measures 360° orientation using Giant Magneto Resistance principle. High resolution 15-bit absolute angle measurement. Compact DSO 8-pin surface mount package. Wide supply voltage and temperature operating range. SPI-compatible synchronous serial communication interface.
Low power consumption with 16 mA supply current. Automotive AEC-Q100 certified for quality assurance. Internal autocalibration for long-term measurement stability.
This 2 axis surface inclinometer is ideal for applications in industrial measurement, automotive angle sensing, robotics, and embedded motion detection systems. It offers a durable and precise solution for orientation sensing where high reliability and accuracy are essential.
Explore more high-performance sensor ICs in the Electronics & Electricals Semiconductor Motion Sensor ICs category on EnvMart for your technical and commercial needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inclinometer sensor measures full 360° angle orientation using integrated Giant Magneto Resistance technology, providing precise sine and cosine angle measurements.
It supports bi-directional synchronous serial communication compatible with SPI standards, allowing for effective data transmission.
The sensor provides a high resolution of 15-bit for absolute angle measurements, enabling precise detection.
The sensor has compact dimensions of 5 mm in length, 4 mm in width, and 1.45 mm in height, suitable for surface mount applications.
The supply current is 16 mA, which supports efficient operation in embedded systems.
It is compliant with the automotive AEC-Q100 standard, ensuring robustness in automotive applications.
Yes, it includes an autocalibration algorithm that enhances measurement stability and accuracy over long-term use.
The sensor is designed for surface mount integration, facilitating easy installation on circuit boards.
The sensor has a frequency response range from 3.8 MHz to 4.3 MHz, enabling effective signal processing.
This model is suitable for applications in industrial measurement, automotive angle sensing, robotics, and embedded motion detection systems.
