TE Connectivity 2 Axis Surface Accelerometer 3 V to 5.5 V, 3 Wire, TO-5 Package, 3-Pin 805M1-0020
Specifications
| Country of Origin | China |
|---|---|
| Brand | TE Connectivity |
| Height | 11.5mm |
| Length | 8.89mm |
| Model | 805M1-0020 |
| SENSITIVITY | 100mV/g |
| Technology | Analogue |
| Sensor Type | Accelerometer |
| Mount Type | Surface |
| Series | TO-5 |
| Maximum Operating Temperature | 100°C |
| Package Type | TO-5 |
| Minimum Operating Temperature | -40°C |
| Number of axis | 2 |
| Interface Type | 3 Wire |
| Standards/Approvals | NIST Traceable Amplitude Calibration at 80Hz |
| Pin Count | 3 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 3V |
| Supply Current | 800μA |
| Maximum Frequency Response | 12000Hz |
| Minimum Frequency Response | 0.4Hz |
Key Features
- Offers a dynamic range from ±20g to ±500g for accurate vibration sensing.
- Features a flat frequency response up to 12,000 Hz.
- Designed with surface mount TO-5 package and 3 pins.
- Operates reliably within temperature range of -40°C to 100°C.
- Provides high sensitivity of 100 mV/g and low supply current of 800 μA.
- Includes NIST traceable amplitude calibration at 80 Hz.
- Compact dimensions with length 8.89 mm and height 11.5 mm.
- Suitable for industrial, laboratory, and motion sensing applications.
Product Description
TE Connectivity 805M1-0020 is a high precision 2 axis surface accelerometer manufactured with analogue sensing technology. It requires a minimum supply voltage of 3 V, with an operating voltage range up to 5.5 V, and utilizes a 3 wire interface for signal output.
The accelerometer features a TO-5 package type with 3 pins and is designed for surface mounting providing a compact and robust sensor solution with dimensions of 8.89 mm length and 11.5 mm height. This makes it adaptable for diverse use cases in motion detection and vibration analysis.
It operates effectively across a wide temperature range from -40°C to 100°C, ensuring reliable performance in harsh industrial environments. The sensor offers a dynamic acceleration range from ±20g to ±500g with a flat frequency response extending up to 12 kHz, enabling accurate measurement of high frequency vibrations.
The device sensitivity is rated at 100 mV/g and it consumes a low supply current of 800 μA, making it energy efficient for continuous monitoring applications. Calibration is traceable to NIST standards at 80 Hz, guaranteeing precision and quality compliance.
Applications include industrial machinery monitoring, laboratory testing, vibration diagnostics, and other motion sensing requirements where high-frequency accelerations must be captured reliably.
Offers a dynamic range from ±20g to ±500g for accurate vibration sensing. Features a flat frequency response up to 12,000 Hz. Designed with surface mount TO-5 package and 3 pins. Operates reliably within temperature range of -40°C to 100°C.
Provides high sensitivity of 100 mV/g and low supply current of 800 μA. Includes NIST traceable amplitude calibration at 80 Hz. Compact dimensions with length 8.89 mm and height 11.5 mm. Suitable for industrial, laboratory, and motion sensing applications.
Explore more high-quality Motion Sensor ICs and accelerometers at EnvMart for precise industrial and laboratory instrumentation.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model offers a dynamic range from ±20g to ±500g, allowing for accurate vibration sensing across a wide spectrum of accelerations.
It features a flat frequency response up to 12,000 Hz, enabling it to accurately measure high-frequency vibrations.
The compact dimensions of this unit are 8.89 mm in length and 11.5 mm in height, making it suitable for various applications.
It operates reliably within a temperature range of -40°C to 100°C, ensuring performance in harsh environments.
The accelerometer requires a minimum supply voltage of 3 V and can operate up to a maximum of 5.5 V.
It has a sensitivity rating of 100 mV/g, which allows for precise measurement of acceleration.
This model uses a 3 wire interface for signal output, facilitating easy integration into various systems.
Yes, it includes NIST traceable amplitude calibration at 80 Hz, ensuring compliance and accuracy.
It consumes a low supply current of 800 μA, making it energy efficient for continuous monitoring applications.
This model is designed for surface mounting, providing a robust solution for various applications.
It is suitable for industrial machinery monitoring, laboratory testing, vibration diagnostics, and other motion sensing requirements.
This accelerometer is manufactured with analogue sensing technology, providing reliable performance for motion detection.
