TE Connectivity Slide Rotary Coded DIP Switch Through Hole Mount 50mΩ Contact Resistance 1825002-9
Specifications
| Country of Origin | India |
|---|---|
| Brand | TE Connectivity |
| Mount Type | Through Hole |
| Actuator Type | Slide |
| Contact Resistance | 50mΩ |
| KNITTER-SWITCH 6 Way Through Hole DIP Switch 6PBrand | KNITTER-SWITCH |
| TE Connectivity 6 Way PCB DIP Switch SPSTBrand | TE Connectivity |
Key Features
- Through hole mount for secure PCB fitting.
- Slide actuator type with extended and flush actuator options.
- Gold flash plated contacts for enhanced conductivity.
- Black PPS housing ensuring durability and chemical resistance.
- 7.5 x 3.5 mm size with 2.54 mm centerline for compact design.
- High pressure wiping contact enables cleaning without tape seal.
- Capable of withstanding vapor phase reflow and wave soldering.
- Auto insertable design improves production efficiency.
Product Description
TE Connectivity 1825002-9 Slide Rotary Coded DIP Switch is a high-quality electronic component designed for precise control applications. Featuring a through hole mount configuration and a slide actuator type, this switch integrates seamlessly onto PCBs with a 2.54 mm centerline and a compact 7.5 x 3.5 mm footprint.
The switch contacts are gold flash plated, providing reliable conductivity and corrosion resistance, housed within a robust black PPS casing that withstands harsh chemical environments. Its high pressure wiping contact system ensures excellent electrical connection and allows cleaning using aqueous or solvent solutions without requiring tape sealing.
Suitable for industrial automation, electronics manufacturing, and control systems, this DIP switch can endure vapor phase reflow and wave soldering processes, ensuring robust assembly reliability. Both ADE series with extended slide actuators and ADF series with flush actuators are available, catering to varied design preferences.
This auto insertable switch simplifies manufacturing workflows and improves production efficiency, making it ideal for mass PCB assembly. Its low contact resistance of 50mΩ ensures minimal signal loss for sensitive electronic circuits.
Through hole mount for secure PCB fitting. Slide actuator type with extended and flush actuator options. Gold flash plated contacts for enhanced conductivity. Black PPS housing ensuring durability and chemical resistance.
7.5 x 3.5 mm size with 2.54 mm centerline for compact design. High pressure wiping contact enables cleaning without tape seal. Capable of withstanding vapor phase reflow and wave soldering. Auto insertable design improves production efficiency.
This product is highly suited for electronics, industrial automation, and manufacturing sectors demanding dependable and easy-to-assemble Rotary Coded DIP Switches. Navigate EnvMart’s electronics category for related switch components and advanced connectivity solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The contact resistance of this DIP switch is 50mΩ, ensuring minimal signal loss for sensitive electronic circuits.
This model utilizes a through hole mount configuration, allowing for secure fitting onto printed circuit boards (PCBs).
This switch is available with two actuator options: an extended slide actuator and a flush slide actuator, catering to different design preferences.
The dimensions of this switch are 7.5 mm x 3.5 mm, with a centerline of 2.54 mm for a compact design.
Yes, it is capable of withstanding vapor phase reflow and wave soldering processes, ensuring robust assembly reliability.
The switch is housed in a black PPS casing, which provides durability and chemical resistance.
Yes, its auto insertable design simplifies manufacturing workflows and improves production efficiency, making it ideal for mass PCB assembly.
This model is suitable for industrial automation, electronics manufacturing, and control systems.
It features gold flash plated contacts, which enhance conductivity and provide corrosion resistance.
The high pressure wiping contact system ensures excellent electrical connection and allows for cleaning without requiring tape sealing.
The country of origin for this DIP switch is India.
The 2.54 mm centerline allows for compatibility with standard PCB layouts, facilitating easier integration into electronic designs.
