Vishay Single Layer Ceramic Capacitor 220 pF 1kV DC ±10 % S3N Dielectric Through Hole Radial Lead F Series F221K25S3NN63J5R
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 1kV dc |
| Diameter | 6.5mm |
| Brand | Vishay |
| Height | 40mm |
| Model | F221K25S3NN63J5R |
| Width | 330mm |
| Mount Type | Through Hole |
| Series | F |
| Maximum Operating Temperature | 125°C |
| Tolerance | ±10 % |
| Capacitance | 220pF |
| Minimum Operating Temperature | -30°C |
| Terminal type | Radial |
| Dissipation Factor | 0.2% |
| Standards/Approvals | RoHS, EC |
| Package/Case | Disc |
| Pin Count | 2 |
| Dielectric | S3N |
| Suppression Class | Class I |
Key Features
- This capacitor features a radial lead, through hole mount type for easy PCB integration.
- S3N dielectric material ensures stable performance at high frequencies.
- Capable of operating at temperatures ranging from -30°C to 125°C.
- Class I suppression class with a low dissipation factor of 0.2% supports high efficiency.
- Suitable for electronic circuits including SMPS, high frequency ballasts, snubber, and high voltage applications.
- The epoxy-resin encapsulation is flame resistant to UL 94 V-0 standards.
- Compliance with RoHS and EC standards guarantees environmental safety.
Product Description
Vishay F221K25S3NN63J5R single layer ceramic capacitor is designed for high performance in electronic circuits requiring precision and reliability. This capacitor has a capacitance of 220 pF and a voltage rating of 1kV DC with ±10 % tolerance, ideal for applications where stable capacitance at high voltage and frequency is essential.
The capacitor utilizes S3N Class 1 ceramic dielectric material, offering low losses and high capacitance density in a compact disc form factor. The radial lead through hole mount with kinked leads facilitates easy and secure PCB assembly. It withstands maximum operating temperatures up to 125°C, and minimum operating temperature down to -30°C, supporting broad environmental conditions.
Its construction includes a ceramic disc with silver-plated surfaces and tinned copper leads, encapsulated in flame-resistant epoxy resin compliant with UL 94 V-0. These features ensure high reliability and safety in SMPS, HF ballast, snubber circuits, and other high voltage applications.
The capacitor conforms to RoHS and EC standards, ensuring regulatory compliance. It offers stable capacitance behavior and low dissipation factor at 0.2 %, making it suitable for sensitive signal processing and power electronics.
High reliability with low losses. Compact size offering high capacitance per volume. Flame-resistant epoxy encapsulation enhances safety. Wide temperature range operation from -30°C to 125°C. Through hole radial lead design for robust mounting.
Compliance with international environmental standards.
This Vishay capacitor is an excellent choice for industrial, laboratory, manufacturing, and power electronics applications requiring dependable ceramic capacitors with high voltage and temperature ratings. Explore more products in the Single Layer Ceramic Capacitors category on EnvMart for comprehensive electronic component solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The capacitance value of this model is 220 pF.
This capacitor has a voltage rating of 1kV DC.
It operates within a temperature range of -30°C to 125°C.
This model features a through hole mount type for easy PCB integration.
It utilizes S3N dielectric material, which ensures stable performance at high frequencies.
The capacitor has a diameter of 6.5 mm and a height of 40 mm.
The dissipation factor is 0.2%, supporting high efficiency in applications.
Yes, it complies with RoHS and EC standards, ensuring environmental safety.
It has a suppression class of Class I, suitable for various electronic circuits.
This capacitor features a radial terminal type with kinked leads for secure mounting.
It is suitable for electronic circuits including SMPS, high frequency ballasts, and snubber circuits.
The country of origin for this capacitor is India.
