Vishay Single Layer Ceramic Capacitor 680 pF 1 kV dc ±10 % S3N Dielectric Through Hole Radial Terminal 125 F681K29S3NN63J5R
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 1kV dc |
| Diameter | 7.5mm |
| Brand | Vishay |
| Height | 40mm |
| Model | F681K29S3NN63J5R |
| Mount Type | Through Hole |
| Series | F |
| Maximum Operating Temperature | 125°C |
| Tolerance | ±10 % |
| Capacitance | 680pF |
| Minimum Operating Temperature | -30°C |
| Terminal type | Radial |
| Dissipation Factor | 0.2% |
| Standards/Approvals | RoHS, EC |
| Package/Case | Disc |
| Pin Count | 2 |
| Dielectric | S3N |
| Suppression Class | Class I |
Key Features
- Utilizes S3N dielectric for high reliability and low losses.
- Features ±10 % capacitance tolerance for precise performance.
- Disc package case with radial terminal type and kinked leads.
- Operates reliably up to maximum temperature of 125 °C.
- Designed for electronic circuits including SMPS, high frequency ballast, and snubber circuits.
- Rated for minimum operating temperature down to -30 °C.
- Provides high capacitance in compact 7.5 mm diameter and 40 mm height form factor.
- Complies with RoHS and EC standards for environmental safety.
Product Description
Vishay F681K29S3NN63J5R is a single layer ceramic capacitor with 680 pF capacitance, rated for 1 kV dc voltage and ±10 % tolerance. It employs an S3N dielectric material, designed for low losses and high reliability in electronic circuits.
This capacitor is configured as a disc package featuring radial terminal type with kinked leads, allowing secure through-hole mounting in printed circuit boards. It measures 7.5 mm in diameter and 40 mm in height and can withstand operating temperatures from -30 °C up to a maximum of 125 °C, making it suitable for demanding environmental conditions.
With a dissipation factor of 0.2 %, it ensures efficient energy performance and is compliant with RoHS and EC environmental standards. The capacitor is commonly used in switched-mode power supplies (SMPS), high-frequency ballast applications, snubber circuits, and other high voltage electronic designs requiring class I suppression characteristics.
The design includes silver-plated ceramic discs connected via tinned copper leads with diameters between 0.6 mm and 0.8 mm, ensuring robust electrical and mechanical connections. Its epoxy-resin encapsulation provides flame resistance complying with UL 94 V-0 standards.
High reliability and low losses in compact size. Robust construction with silver plating and epoxy encapsulation. Wide operating temperature range from -30 °C to 125 °C. Compatible with various industrial and commercial electronic applications.
RoHS and EC compliant for environmental safety.
This capacitor is ideal for use in industrial, manufacturing, telecommunications, and commercial electronic equipment requiring dependable and compact passive components. Its specifications ensure optimal performance in circuits sensitive to loss and capacitance precision.
Explore the full range of Vishay capacitors and electronic components on EnvMart for reliable procurement solutions.
Explore more products in our Single Layer Ceramic Capacitors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a capacitance value of 680 pF, providing precise performance for various electronic applications.
It is rated for a maximum voltage of 1 kV dc, making it suitable for high voltage applications.
It employs an S3N dielectric, which is known for its high reliability and low losses in electronic circuits.
The capacitor has a diameter of 7.5 mm and a height of 40 mm, allowing for compact installation in electronic circuits.
It operates reliably within a temperature range from -30 °C to a maximum of 125 °C, suitable for demanding environments.
The capacitance tolerance is ±10 %, ensuring precise performance in electronic applications.
This unit features a through hole mounting type, designed for secure installation on printed circuit boards.
It has a dissipation factor of 0.2 %, which contributes to efficient energy performance in circuits.
It complies with RoHS and EC standards, ensuring environmental safety in its application.
This model has a radial terminal type with kinked leads, allowing for secure connections in electronic circuits.
It is commonly used in switched-mode power supplies (SMPS), high-frequency ballast applications, and snubber circuits.
The capacitor is manufactured in India, ensuring compliance with local manufacturing standards.
