Vishay Single Layer Ceramic Capacitor 560 pF 2kV dc ±10 % S3N Dielectric Through Hole Radial Lead 125°C F F561K39S3NP63K7R

Vishay F561K39S3NP63K7R is a high-quality single layer ceramic capacitor designed for industrial and electronic circuit applications requiring low loss and high capacitance per volume.

This capacitor employs an S3N dielectric ceramic class 1 material, making it ideal for switched-mode power supply (SMPS) circuits, high frequency ballast applications, snubber circuits, and various high voltage environments.

It features a disc type ceramic construction with silver-plated electrodes on both sides and kinked tinned copper leads available in diameter sizes of 0.6 mm or 0.8 mm and lead spacings of 5 mm, 7.5 mm, or 10 mm. The epoxy resin encapsulation conforms to UL 94 V-0 flammability standards, ensuring durability and safety in demanding industrial settings.

With a capacitance of 560 pF, a rated voltage of 2 kV dc, and a tolerance of ±10 %, this component maintains stable performance across a wide temperature range from -30 °C minimum to 125 °C maximum operating temperature.

The dissipation factor of 0.2% promotes efficient circuit operation by minimizing power losses. The Vishay F series capacitors comply with IEC 60384-9 and RoHS directives, reflecting careful design and environmentally responsible manufacturing.

Utilizes S3N dielectric for SMPS and high voltage snubber circuits. Epoxy resin encapsulation provides flame resistance to UL 94 V-0 standards. Radial through hole mounting with kinked tinned copper leads ensures secure PCB placement.

Disc dimensions of 40 mm height, 18 mm width, and 10 mm diameter facilitate compact board layouts. Low dissipation factor enhances efficiency in power electronic applications. Wide operating temperature range allows for use in harsh industrial environments.

Compliance with RoHS and IEC 60384-9 standards guarantees quality and safety. 2kV dc voltage rating provides robust protection in high voltage circuits.

This single layer ceramic capacitor is essential in industrial electronics, power management, construction of high voltage devices, and advanced manufacturing systems. It is an ideal choice for ensuring stability and reliability in circuits requiring stable capacitance and high voltage endurance.
