SMC Pneumatic 3/2 NC Solenoid/Spring Valve SY100 Series 24V DC 0.7MPa 7.85NL/min

Free Delivery in India | Lowest Global Shipping Charges

SMC Pneumatic 3/2 NC Solenoid/Spring Valve SY100 Series 24V DC 0.7MPa 7.85NL/min



Category Pneumatic Solenoid Valve Brand SMC Condition New

Specifications

Country of Origin	France
Voltage	24V dc
Brand	SMC
Body Material	Resin
Maximum Operating Pressure	0.7 Mpa
Model	SY100
Width	1mm
Mount Type	Manifold
Series	SY100
Number Of Ports	3
Maximum Operating Temperature	50°C
Port Type	Type R, Type P, Type A
Seal Material	Nitrile Rubber (NBR)
Actuation Type	Solenoid/Spring
Maximum Flow Rate	7.85NL/min
Standards/Approvals	RoHS
Minimum Pilot Pressure	0MPa
Valve Function	3/2 NC
Electrical Connection Type	Grommet, L-Plug Connector, M-Plug Connector
Solenoid Power Consumption	0.55W

Key Features

The valve features solenoid and spring actuation for reliable 3/2 NC operation.
Seal material consists of durable nitrile rubber (NBR).
Operates at temperatures up to 50°C with low solenoid power consumption of 0.55W.
Electrical connections include Grommet, L-Plug, and M-Plug connectors for flexible installation.
The valve body is constructed from resin for lightweight and corrosion resistance.
Designed for pressure or vacuum pneumatic applications.
RoHS compliant and manufactured in France ensuring quality standards.

Product Description

SMC SY114-5LOZ-Q Pneumatic Solenoid Valve is a 3/2 port normally closed valve from the SY100 series, designed for efficient pneumatic control in industrial applications. It operates at 24V DC voltage with a maximum operating pressure of 0.7 MPa, delivering a maximum flow rate of 7.85 NL/min. The valve features solenoid and spring actuation, with a low power consumption of 0.55W, making it energy-efficient for continuous use.

The valve body is made of durable resin, offering corrosion resistance and lightweight construction. Seal materials use nitrile rubber (NBR), ensuring reliable sealing under operating temperatures up to 50°C. The valve supports manifold mounting and includes three port types: Type R, Type P, and Type A, accommodating various installation requirements.

Electrical connections are designed for versatility with Grommet, L-Plug Connector, and M-Plug Connector options. This solenoid valve is RoHS compliant and manufactured in France, adhering to stringent quality standards.

Ideal for use in pneumatic systems controlling pressure or vacuum operations in industries such as automation, manufacturing, and fluid power systems. The valve includes features such as a non-locking manual override and compatibility with VJ100 series sub-bases, enhancing installation flexibility and maintenance.

The SY114-5LOZ-Q valve operates reliably within a pressure range of 0 MPa to 0.7 MPa. Its compact width of 1 mm allows for efficient space utilization in control panels. Suitable for industrial pneumatic applications requiring precise valve control.

Includes hazard-free certification with no hazardous area approvals needed. Designed for long operational life with minimal power consumption and maintenance needs.

This product provides a dependable pneumatic controlling solution, enhancing machine performance and operational safety in fluid power and automation systems. For more technical pneumatic and solenoid valves, explore the Industrial Valves category at EnvMart.
