TE Connectivity Buchanan Series Pluggable Terminal Block, 3-Contact, 5.08 mm Pitch, 1 Row, 15A, 300V, Female 796638-3

Free Delivery in India | Lowest Global Shipping Charges

TE Connectivity Buchanan Series Pluggable Terminal Block, 3-Contact, 5.08 mm Pitch, 1 Row, 15A, 300V, Female 796638-3

Name: TE Connectivity Buchanan Series Pluggable Terminal Block, 3-Contact, 5.08 mm Pitch, 1 Row, 15A, 300V, Female 796638-3
Brand: TE Connectivity
SKU: 217896
Price: 1.53 USD
Availability: InStock



Category Pluggable Terminal Block Brand TE Connectivity Condition New

Specifications

Country of Origin	Italy
Voltage	300V
Brand	TE Connectivity
Colour	Green
Orientation	Right Angle
Current	15A
Model	796638-3
Housing Material	Polyamide
Series	Buchanan
Number of Rows	1
Pitch	5.08mm
Number of Contacts	3
Connector Gender	Female
Minimum Wire Size mm²	0.05mm²
Maximum Wire Size mm²	3mm²
Minimum Wire Size AWG	12AWG
Maximum Wire Size AWG	30AWG
Wire Connection Method	Solder

Key Features

This terminal block supports a current rating of 15A and voltage rating of 300V.
The housing is made of durable green polyamide material ensuring insulation and mechanical stability.
It features a female connector gender and right angle orientation for flexible PCB mounting.
Wire connection is by solder method suitable for a wide wire size range from 0.05 mm² to 3 mm² (12 AWG to 30 AWG).
The terminal block is part of the Buchanan series, designed for industrial and electronic PCB applications.
Originating from Italy, this product ensures quality manufacturing standards.
It does not include any special approvals or certifications but complies with UL 94V-0 standards for flammability.
This product is ideal for use in industrial machinery, control panels, and electrical devices requiring secure pluggable connections.

Product Description

TE Connectivity 796638-3 Buchanan Series Pluggable Terminal Block offers a reliable and flexible way to connect wires in electronic and industrial equipment. Featuring 3 contacts arranged in a single row with a 5.08 mm pitch, this terminal block supports up to 15A current and 300V voltage, making it suitable for a variety of medium-power applications.

The connector housing is made from green polyamide 6.6 GF, providing strong mechanical stability and electrical insulation. Designed as a female connector with a right angle mount, it facilitates efficient PCB layout with easy solder wire connections. It accepts wire sizes from 0.05 mm² up to 3 mm², equivalent to 12 AWG to 30 AWG, accommodating a broad range of wiring needs.

This terminal block belongs to the widely used Buchanan series and is ideal for applications in industrial automation, control systems, power supplies, and electronic devices requiring removable terminal connections. The product is manufactured in Italy under strict quality standards and complies with UL 94V-0 flammability ratings.

Its design allows easy insertion into machinery and equipment, improving production efficiency and serviceability. The soldered wire connection method ensures a secure and durable electrical contact. This product has no additional certifications but meets industry reliability and safety standards.

This is a Pluggable Terminal Block with 3 contacts and 1 row configuration. Pitch is 5.08 mm for compatibility with standard PCB layouts. Rated for a current of 15A and voltage of 300V. Housing made of green polyamide ensures durability and insulation.

Accepts solder wire connections from 0.05 mm² to 3 mm² (12 AWG to 30 AWG). Right angle orientation facilitates versatile PCB mounting. Manufactured in Italy, ensuring quality control.
