HARWIN Datamate J-Tek Series Straight Through Hole PCB Header, 4 Contacts, 2 mm Pitch, 2 Row, Shrouded M80-5100442
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Voltage | 1.2kV |
| Brand | HARWIN |
| Orientation | Straight |
| Current | 3A |
| Model | M80-5100442 |
| Mount Type | Through Hole |
| Housing Material | Polyphenylene Sulphide |
| Contact Material | Phosphor Bronze |
| Series | Datamate J-Tek |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Contact Plating | Gold |
| Number of Contacts | 4 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Tail Pin Length | 3.3mm |
Key Features
- Shrouded design providing reliable connection protection.
- Double row, through-hole mount type for board-to-board and wire-to-board applications.
- Phosphor bronze contacts with gold plating ensure excellent conductivity and corrosion resistance.
- Housing made from durable polyphenylene sulphide material for thermal stability.
- Operates under temperatures ranging from -55°C to 125°C.
- Rated for 3A current and withstands up to 1.2 kV voltage.
- Tail pin length measures 3.3 mm for secure solder termination.
- Male contact gender with 2 row pitch of 2 mm.
Product Description
HARWIN M80-5100442 Datamate J-Tek Series Straight Through Hole PCB Header is a high-reliability connector designed for electronic and electrical applications where secure, durable connections are required. Featuring a shrouded, double-row configuration with 4 contacts and a 2 mm pitch, this PCB header suits board-to-board and wire-to-board connector systems.
The contacts are manufactured from phosphor bronze with a gold plating finish to enhance conductivity and prevent corrosion, critical for maintaining signal integrity in industrial and commercial electronics. The housing uses polyphenylene sulphide material providing excellent thermal resistance and mechanical strength, supporting operation in temperatures from -55°C up to 125°C.
This connector is rated for a current of 3 amperes and a voltage rating of 1.2 kV making it suitable for a range of power and signal applications. Tail pins are 3.3 mm long ensuring reliable solder termination in through-hole mounting on printed circuit boards.
The male contact gender design and shrouded structure increase durability and protect contacts during handling and operation. Manufactured in the United Kingdom under stringent quality controls, the M80-5100442 model is ideal for use in electronic manufacturing, industrial control systems, instrumentation, telecom, aerospace, defense, and automotive sectors.
HARWIN’s Datamate J-Tek series is renowned for precision and durability in harsh environments, making this product a dependable choice for demanding industrial and laboratory electrical connectivity needs.
Shrouded double row with 4 contacts for robust connections. Gold plated phosphor bronze contacts ensure corrosion resistance. Polyphenylene sulphide housing for high thermal endurance. Operational temperature range from -55°C to 125°C.
Rated at 3A current and 1.2 kV voltage for versatile use. Through-hole mounting type with 3.3 mm tail pin length. Male gender contacts suited for board-to-board and wire-to-board systems. Reliable UK manufactured quality ensuring industrial-grade performance.
Explore further in EnvMart’s Electronics & Electricals category for more PCB connector solutions from trusted brands including HARWIN.
Explore more products in our Electronics Components category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The HARWIN M80-5100442 PCB header is rated for a maximum voltage of 1.2 kV.
This connector is rated for a current of 3A.
The contacts are made from phosphor bronze with gold plating, and the housing is constructed from polyphenylene sulphide material.
It operates within a temperature range of -55°C to 125°C.
This model features a 2 mm pitch and has 4 contacts arranged in a double-row configuration.
The HARWIN M80-5100442 is designed for through-hole mounting.
The tail pin length measures 3.3 mm, ensuring reliable solder termination.
This connector is suitable for both board-to-board and wire-to-board applications.
The contacts in this model are male gender contacts.
The shrouded design provides reliable connection protection and increases durability during handling and operation.
This connector is manufactured in the United Kingdom under stringent quality controls.
This model utilizes solder termination for secure connections.
