Preci-Dip 12 Contact 2.54 mm Pitch 2 Row Straight Through Hole Spring Loaded Connector 813-S1-012-10-014101

Free Delivery in India | Lowest Global Shipping Charges

Preci-Dip 12 Contact 2.54 mm Pitch 2 Row Straight Through Hole Spring Loaded Connector 813-S1-012-10-014101

Name: Preci-Dip 12 Contact 2.54 mm Pitch 2 Row Straight Through Hole Spring Loaded Connector 813-S1-012-10-014101
Brand: Preci-Dip
SKU: 215353
Price: 14.51 USD
Availability: InStock



Category Connector Brand Preci-Dip Condition New

Specifications

Country of Origin	Switzerland
Voltage	150V
Brand	Preci-Dip
Orientation	Straight
Current	3.5A
Model	813-S1-012-10-014101
Mount Type	Through Hole
Housing Material	Fibreglass Reinforced Polyethylene Terephthalate
Contact Material	Brass
Series	813
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	12
Contact Gender	Male
Shrouded/Unshrouded	Shrouded

Key Features

Rated for 3.5A current and 150V voltage.
Shrouded straight orientation enhances reliable connection.
Constructed with brass contact material plated in gold for excellent conductivity.
Fibreglass reinforced polyethylene terephthalate housing ensures durability.
Operates reliably between -55°C and 125°C temperature range.
Features solder termination type suitable for through hole mount.
Provides low resistance and stable electrical contact with spring-loaded design.
Compact design with a 4 mm plastic body height and 1.4 mm plunger stroke length.

Product Description

Preci-Dip 813-S1-012-10-014101 spring loaded connector is a high reliability 12 contact PCB connector with 2.54 mm pitch arranged in 2 rows. This shrouded connector features a straight orientation and employs spring loaded contacts (SLC) mounted through holes for stable and low resistance electrical connections.

The connector housing is made from fibreglass reinforced polyethylene terephthalate which provides excellent mechanical strength and thermal stability, supporting operation between -55°C to 125°C. Contacts are crafted from brass with gold plating to ensure superior conductivity and resistance to corrosion, enhancing long-term performance.

Each contact has a spring loaded plunger with a stroke length of 1.4 mm and a plastic body height of 4 mm, supporting current loads up to 3.5A and voltage requirements up to 150V. The termination type is solder compatible for secure mounting on PCBs, suitable for through hole technology.

This connector is ideal for industrial, electronics manufacturing, power distribution, and general PCB interconnection. Its robust design and compliance with UL 94V-0 standard ensure safe and reliable use in demanding environments.

Rated for 3.5A current and 150V voltage. Shrouded straight orientation enhances connection stability. Gold plated brass contacts ensure excellent conductivity. Durable fibreglass reinforced housing material offers thermal resistance.

Wide operating temperature range from -55°C to 125°C. Through hole solder termination ensures firm PCB mounting. Compact design with 4 mm housing height and 1.4 mm plunger stroke. Low resistance spring loaded contacts reduce micro-discontinuities under vibration.

Manufactured in Switzerland under new condition. Applications include electronic components, power connectors, PCB headers, and industrial instrumentation. Explore more electronic Connectors and PCB header solutions at EnvMart for enhanced assembly and production efficiency.
