Panasonic Surface Mount DPDT Signal Relay 4.5V DC Coil 2A Switching Current TX2-4.5V-TH
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Panasonic |
| Height | 8.2mm |
| Length | 15mm |
| Model | TX2-4.5V-TH |
| Width | 7.4mm |
| Mount Type | Surface |
| Contact Material | Gold Plated |
| Series | G6S |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 2A |
| Terminal type | PCB Terminal |
| Standards/Approvals | RoHS |
| Coil Resistance | 145Ω |
| Coil Voltage | 4.5V dc |
| Switching DC Voltage | 220V dc |
| Switching AC Voltage | 220V ac |
| Coil Power | 140mW |
| UL recognised, | CSA,:BSI |
Key Features
- Operates with a coil voltage of 4.5V DC and low coil power of 140mW for high energy efficiency.
- Supports dual pole double throw (DPDT) contact configuration for flexible switching.
- Switching capacity up to 2A current and switching voltages of 220V AC/DC ensure versatile use.
- Compact dimensions with length 15mm, width 7.4mm, and height 8.2mm for PCB surface mounting.
- Gold plated contacts provide superior conductivity and corrosion resistance.
- Wide operating temperature range from -40°C to 85°C for reliable performance in harsh environments.
- Sealed construction supports automatic washing and protects against vibration and shock.
- Typical applications include air conditioning control and other high capacity control functions.
Product Description
Panasonic TX2-4.5V-TH is a surface mount signal relay designed for reliable electrical switching in industrial and automation systems. Featuring a 4.5V DC coil and a DPDT (double pole double throw) contact configuration, this relay handles switching currents up to 2A with switching voltages of 220V AC/DC, suitable for high capacity control tasks.
The relay belongs to the TX series with a robust PCB mount design and compact dimensions of 15mm length, 7.4mm width, and 8.2mm height, allowing seamless integration into dense electronic assemblies.
It offers a coil power consumption of only 140mW and coil resistance of 145 Ω, making it energy efficient. The gold plated contacts ensure excellent conductivity and reliability over extended use, while the sealed construction provides excellent vibration resistance and shock protection.
Designed for harsh industrial environments, this relay operates reliably between -40°C to 85°C and is RoHS compliant, reflecting its adherence to environmental and safety standards. The relay supports a 7.5A inrush current capability, enhancing its utility in applications like air conditioning control and other automation control functions requiring surge resistance.
Compact surface mount design with PCB terminals for efficient assembly. High contact capacity, supporting 2A at 30V DC with surge capability. Gold plated contacts reduce contact resistance and corrosion. Wide operating temperature range suitable for industrial use.
Sealed construction allows automatic washing and protection against contaminants. RoHS compliance ensures environmentally safe manufacturing.
This Panasonic Signal Relay is widely used in industrial automation, HVAC systems, manufacturing process control, and other applications requiring compact, reliable switching components. Its high sensitivity and contact capacity make it a preferred choice for system designers looking for durability and performance in electronic relay components.
Explore more reliable and eco-friendly electrical relay components within the Relay category on EnvMart to enhance your industrial and automation projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay operates with a coil voltage of 4.5V DC.
This model can handle a maximum switching current of 2A.
The dimensions of this relay are 15mm in length, 7.4mm in width, and 8.2mm in height.
It features a dual pole double throw (DPDT) contact configuration for flexible switching.
The relay operates reliably within a temperature range of -40°C to 85°C.
This unit has PCB terminals for surface mounting.
The coil power consumption is 140mW.
The contacts are made of gold plated material, enhancing conductivity and corrosion resistance.
It can switch voltages of up to 220V AC and 220V DC.
Yes, the relay is RoHS compliant, reflecting its adherence to environmental standards.
Typical applications include air conditioning control and other high capacity control functions.
This model supports a 7.5A inrush current capability, enhancing its utility in various applications.
