Panasonic PCB Signal Relay, DPDT Contact Configuration, 4.5V DC Coil, 1A Switching Current, 30W Switching Power AGN2104H

Panasonic AGN2104H is a high-quality PCB Signal Relay designed for reliable switching in compact, demanding electronic applications. It incorporates a 4.5V DC coil and supports a switching current of 1A, providing robust performance for Signal Relay operations. The relay features DPDT (Double Pole Double Throw) contact configuration with gold plated twin crossbar contacts to deliver excellent contact reliability and minimal resistance.

The compact and slim form factor with dimensions 9mm (height) x 5.7mm (width) x 10.6mm (length) enables increased packaging density on PCBs. Its sealed construction allows for automatic washing processes and ensures protection against environmental contaminants, contributing to long-term stability.

This relay offers outstanding surge resistance and high vibration and shock resistance, making it ideal for industrial and commercial uses. Operating over a wide temperature range from -40°C to 85°C, the relay performs reliably in various environmental conditions.

With a coil resistance of 202.5Ω and coil power consumption of only 100mW, the device is energy efficient while maintaining performance. Switching voltage capacities include up to 125V AC and 110V DC, making it applicable to a broad range of electrical circuits.

Its through-hole terminal type facilitates secure PCB mounting and electrical connectivity. Panasonic's AGN Series relays serve in applications such as telecommunications equipment, measurement instruments, and audio-visual devices, ensuring versatile utility.

This product complies with RoHS standards and is manufactured in Japan, guaranteeing adherence to strict quality and environmental standards. Compact slim body measuring 9mm height, 5.7mm width, and 10.6mm length. High surge resistance and sealed construction for durability and automatic washing.

Gold plated twin crossbar contacts ensure high contact reliability. Suitable for PCB mounting with through-hole terminal type. Operating temperature range from -40°C to 85°C ensures broad environmental compatibility. Switching AC voltage rating of 125V and DC voltage rating of 110V for versatile electrical applications.

Low coil power consumption at 100mW supporting efficient operation. Typical use in telecommunications, measurement, and audio-visual equipment. RoHS compliant and manufactured in Japan ensuring high quality standards. Explore more high-performance relays and signal conditioning products from Panasonic and related brands on EnvMart for your industrial, laboratory, and commercial needs.
