HARTING D-Sub 37 Way Right Angle 2.76 mm Pitch Through Hole D-Sub Connector with 4 to 40 UNC Threaded Insert 09664526612

Free Delivery in India | Lowest Global Shipping Charges

HARTING D-Sub 37 Way Right Angle 2.76 mm Pitch Through Hole D-Sub Connector with 4 to 40 UNC Threaded Insert 09664526612

Name: HARTING D-Sub 37 Way Right Angle 2.76 mm Pitch Through Hole D-Sub Connector with 4 to 40 UNC Threaded Insert 09664526612
Brand: HARTING
SKU: 212988
Price: 18.96 USD
Availability: InStock



Category D-Sub Connector Brand HARTING Condition New

Specifications

Country of Origin	Romania
Voltage	1kV
Brand	HARTING
Orientation	Right Angle
Current	7.5A
Mount Type	Through Hole
Housing Material	Steel
Contact Material	Copper Alloy
Series	D-Sub
Mounting Hardware	4 to 40 UNC Threaded Insert
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Pitch	2.76mm
Contact Plating	Gold
Number of Contacts	37
Contact Gender	Female
Connector Gender	Female
Connector Type D	D-Sub
D-Sub Shell Size	DS-4

Key Features

This right angle connector features 4 to 40 UNC threaded insert mounting hardware for secure assembly.
Constructed with a plated steel housing ensuring durability and mechanical protection.
Contacts are made from copper alloy with gold plating for reliable conductivity and corrosion resistance.
Rated for a maximum current of 7.5A and operating voltage of up to 1kV for industrial applications.
Operates reliably in harsh conditions from -55°C to 125°C, suitable for demanding environments.
Designed for solder termination and female connector gender, compatible with standard D-Sub configurations.
Complies with IEC 60 807 standards and features stamped pins for excellent mating cycles.

Product Description

HARTING 09664526612 is a 37 Way Right Angle D-Sub Connector with a 2.76 mm pitch, ideal for industrial and electronic power connector applications requiring dependable signal integrity and mechanical strength.

This connector is built with a robust plated steel housing for enhanced durability and mechanical protection. It utilizes stamped copper alloy contacts plated in gold, providing excellent electrical conductivity and corrosion resistance, ensuring signal quality over prolonged use.

Designed for through-hole mounting, it features 4 to 40 UNC threaded insert hardware for secure panel mount installation. The connector is female gender with solder termination type, facilitating easy soldering during PCB assembly.

It operates efficiently over a broad temperature range from -55°C to 125°C, making it suitable for harsh industrial, manufacturing, automation, electronic, and power distribution systems. Rated for 7.5A current and 1kV voltage, it supports varied power and signal applications.

The connector complies with IEC 60 807 standards and employs the DIN 41652 standard D-Sub form factor with stamped pins and board locks, ensuring a stable connection and good mating cycles.

This product is manufactured in Romania, guaranteeing high quality and reliability for professional use cases such as industrial automation, control systems, and communication interfaces.

This right angle connector features 4 to 40 UNC threaded insert mounting hardware for secure assembly. Constructed with a plated steel housing ensuring durability and mechanical protection. Contacts are made from copper alloy with gold plating for reliable conductivity and corrosion resistance.

Rated for a maximum current of 7.5A and operating voltage of up to 1kV for industrial applications. Operates reliably in harsh conditions from -55°C to 125°C, suitable for demanding environments. Designed for solder termination and female connector gender, compatible with standard D-Sub configurations.

Complies with IEC 60 807 standards and features stamped pins for excellent mating cycles. Explore more high-quality HARTING connectors and industrial power components in the EnvMart catalogue.
