HARTING 44 Way Straight 2.29 mm Pitch Through Hole D-Sub Connector with 4 to 40 UNC Threaded Insert Male 09563517512
Specifications
| Country of Origin | China |
|---|---|
| Brand | HARTING |
| Orientation | Straight |
| Current | 2A |
| Mount Type | Through Hole |
| Housing Material | Steel |
| Contact Material | Copper Alloy |
| Mounting Hardware | 4 to 40 UNC Threaded Insert |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Pitch | 2.29mm |
| Contact Plating | Gold |
| Number of Contacts | 44 |
| Contact Gender | Female |
| Connector Gender | Male |
| Connector Type D | Standard |
Key Features
- Features 44 contacts supporting 2A current capacity.
- Constructed with a durable steel housing for enhanced protection.
- Equipped with 4 to 40 UNC threaded inserts for secure mounting.
- Supports operating temperature range from -55°C to 105°C.
- Contacts plated with gold for optimal conductivity and corrosion resistance.
- Termination type is solder with stamped solder pins for reliable attachment.
- Designed as a straight orientation connector for through hole mounting.
- Contact gender is female with male connector gender orientation.
Product Description
HARTING 09563517512 44 Way Straight 2.29 mm Pitch Through Hole D-Sub Connector features a robust steel housing and gold-plated copper alloy contacts designed to ensure high performance and durability in electronic and industrial environments.
This connector provides 44 contacts arranged with a 2.29 mm pitch allowing for high-density connectivity exceeding standard subminiature D connector contact capacity by 70%. It is rated for 2A current and operates reliably in extreme temperatures from -55°C to 105°C.
The product incorporates stamped solder pins designed for through hole mounting, enhancing solder termination reliability. The connector's mounting hardware uses 4 to 40 UNC threaded inserts for strong mechanical stability in applications.
Its straight orientation with male connector gender and female contact gender facilitates versatile connection setups. The connector’s housing is tinned metal, featuring grounding board locks for secure installation and noise reduction.
This high-density D-Sub connector is ideal for industrial, electronic components manufacturing, power connectors, and various commercial applications requiring dependable and compact connectivity solutions.
Features 44 contacts supporting 2A current capacity. Durable steel housing construction with tinned metal shell. 4 to 40 UNC threaded insert mounting for secure assembly. Gold-plated copper alloy contacts for excellent reliability.
Wide operating temperature range from -55°C to 105°C. Stamped solder pins enable dependable solder terminations. Straight orientation for through hole mounting applications. Male connector with female contact gender alignment.
EnvMart catalog offers a broad range of electronic connectors with detailed specifications for easy selection within the Power Connectors and D-Sub Connector categories.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This connector supports a current capacity of 2A.
The contacts are arranged with a pitch of 2.29 mm.
It operates reliably within a temperature range of -55°C to 105°C.
The housing is made of durable steel, and the contacts are composed of gold-plated copper alloy.
It features through hole mounting with 4 to 40 UNC threaded inserts for secure assembly.
This model has a male connector gender and female contact gender.
The termination type is solder, utilizing stamped solder pins for reliable attachment.
It has a total of 44 contacts.
Specific dimensions are not provided, but it is designed for high-density connectivity.
It is ideal for industrial, electronic components manufacturing, and various commercial applications requiring compact connectivity solutions.
Gold plating enhances conductivity and provides corrosion resistance for optimal performance.
The country of origin for this connector is China.
