Bourns 8043 Shielded Wirewound Surface Mount Inductor Ferrite Core 68 μH ±30% 1.2 A IDC Q20 SRU6043
Specifications
| Country of Origin | India |
|---|---|
| Brand | Bourns |
| Height | 4.3mm |
| Length | 8mm |
| Model | SRU6043 |
| Depth | 8mm |
| Packaging | Reel |
| Series | SRU6043 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 68μH |
| Standards/Approvals | RoHS |
| Package/Case | 8043 |
| Maximum DC Current | 1.2A |
| Pin Count | 2 |
| Maximum DC Resistance | 192mΩ |
| Inductance Tolerance | ±30 % |
| Termination Style | Solder |
| Maximum Self Resonant Frequency | 7MHz |
| Minimum Quality Factor | 20 |
| Inductor Construction | Wirewound |
Key Features
- Low profile magnetically shielded wire wound choke construction ensures minimal electromagnetic interference.
- High current rating suitable for compact, high-frequency electronic circuits.
- RoHS compliant with a ferrite core for enhanced magnetic performance.
- Designed for use in DC/DC converters and EMI filters in electronic devices.
- Operating temperature range from -40°C to 125°C for reliable performance under varying conditions.
- Surface mount packaging in 8043 size with solder termination style for ease of assembly.
- Maximum DC resistance of 192 mΩ provides efficient current flow with minimal power loss.
- Quality factor minimum of 20 and maximum self-resonant frequency of 7 MHz to support high-frequency applications.
Product Description
Bourns SRU6043 SRU8043-680Y shielded wirewound Surface Mount Inductor features a ferrite core with 68 μH inductance and ±30% tolerance, designed for compact electronic applications requiring high current capacity and efficient EMI filtering.
This low profile magnetically shielded wire wound choke supports a maximum DC current of 1.2 A and operates reliably within a temperature range of -40°C to 125°C. Its surface mount 8043 package facilitates easy PCB assembly with solder termination style.
The inductor offers a maximum DC resistance of 192 mΩ, maintaining low power losses in circuit designs, and features a minimum quality factor of 20. With a maximum self-resonant frequency of 7 MHz, it is suitable for high-frequency applications including DC/DC converters and EMI filters.
RoHS compliant and moulded, the SRU6043 series ensures durability and stability for industrial, electronic component manufacturing, automotive electronics, telecommunications, and consumer electronic devices.
Packaged on a reel for automated production environments, this inductor aids in enhancing electromagnetic compatibility and filtering unwanted noise signals in sensitive electronic circuits.
Low profile magnetically shielded wire wound choke construction ensures minimal electromagnetic interference. High current rating suitable for compact, high-frequency electronic circuits. RoHS compliant with a ferrite core for enhanced magnetic performance.
Designed for use in DC/DC converters and EMI filters in electronic devices. Operating temperature range from -40°C to 125°C for reliable performance under varying conditions. Surface mount packaging in 8043 size with solder termination style for ease of assembly.
Maximum DC resistance of 192 mΩ provides efficient current flow with minimal power loss. Quality factor minimum of 20 and maximum self-resonant frequency of 7 MHz to support high-frequency applications. Packaged on a reel for streamlined automated insertion during manufacturing.
Moulded wirewound construction ensures durability and stable electrical characteristics. Explore our extensive range of electronic components at EnvMart to find compatible inductors and surface mount devices for your industrial and consumer electronics projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has an inductance of 68 μH with a tolerance of ±30%.
The maximum DC current rating for this inductor is 1.2 A.
It operates reliably within a temperature range of -40°C to 125°C.
The maximum DC resistance is 192 mΩ, allowing for efficient current flow.
The maximum self-resonant frequency is 7 MHz, suitable for high-frequency applications.
This inductor features a ferrite core, which enhances its magnetic performance.
It is packaged on a reel, facilitating automated production environments.
The inductor has a minimum quality factor of 20, supporting its use in high-frequency applications.
This model has dimensions of 8mm in length, 8mm in depth, and a height of 4.3mm.
It uses a solder termination style for ease of assembly on PCBs.
Yes, it is RoHS compliant, ensuring it meets environmental regulations.
It is designed for use in DC/DC converters and EMI filters in electronic devices.
