STMicroelectronics Linear Voltage Regulator Surface Mount Positive Polarity 3-Pin 500μA Quiescent Current 20V KF80BDT-TR
Specifications
| Country of Origin | India |
|---|---|
| Voltage | Regulators STMicroelectronics KF80BDT-TR, Voltage Regulator 20V 3-Pin RS Stock N |
| Brand | STMicroelectronics |
| Height | 2.4mm |
| Length | 6.6mm |
| Model | KF80BDT-TR |
| Width | 6.2mm |
| Mount Type | Surface |
| Series | KFXX |
| Maximum Operating Temperature | 125°C |
| Polarity | Positive |
| Maximum Input Voltage | 20V |
| Quiescent Current | 500μA |
| Minimum Input Voltage | -0.5V |
| Pin Count | 3 |
Key Features
- Operates with a low dropout voltage ensuring efficient power regulation.
- Features a quiescent current of 500μA for low power consumption.
- Compact dimensions of 6.6mm length, 6.2mm width, and 2.4mm height.
- Maximum operating temperature rating of 125°C suitable for demanding environments.
- Designed without automotive certification, tailored for industrial and commercial use.
- Robust surface mount package suitable for high-efficiency PCB designs.
- Supports input voltage range from -0.5V up to 20V for versatile applications.
Product Description
STMicroelectronics KF80BDT-TR is a surface-mount linear voltage regulator designed to provide reliable and precise voltage regulation with a positive polarity configuration. It is built to handle a maximum input voltage of 20V and features a low quiescent current of 500μA, resulting in energy-efficient operation suitable for portable and embedded power management systems.
This 3-pin regulator comes in a compact package measuring 6.6mm in length, 6.2mm in width, and 2.4mm in height, making it ideal for space-constrained designs. Its maximum operating temperature of 125°C assures dependable performance even under high thermal stress commonly encountered in industrial electronic applications.
The device does not have automotive certification but is highly reliable for industrial, commercial electronics, and power management IC use cases requiring stable voltage outputs with low dropout characteristics. The regulator supports a wide input voltage range starting from a minimum of -0.5V up to the high maximum input voltage of 20V.
Key features of the STMicroelectronics KF80BDT-TR include minimal noise and fast transient response, suitable for sensitive electronics requiring clean voltage supplies. It integrates easily into surface mount technology circuits and contributes to efficient power management in industrial controls, instrumentation, and consumer electronics.
Operates with low quiescent current of 500μA ensuring low power losses. Compact surface mount package facilitating automated PCB assembly. Wide operating temperature range up to 125°C for harsh environments. Supports voltage regulation up to 20V maximum input level.
Three-pin construction designed for easy integration into electronic devices. Positive polarity configuration for standard voltage regulation requirements. Ideal for industrial, commercial, and consumer electronics applications.
This product belongs to STMicroelectronics’ KFXX series of LDO low dropout regulators well-regarded for stable voltage regulation and efficient performance across various electronics manufacturing sectors.
Explore more power management ICs and Voltage Regulators at EnvMart’s comprehensive electronics category to find optimal components for your design requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum input voltage for this model is 20V.
It features a low quiescent current of 500μA, ensuring energy-efficient operation.
This model has compact dimensions of 6.6mm in length, 6.2mm in width, and 2.4mm in height.
The maximum operating temperature rating is 125°C, suitable for demanding environments.
It is designed for surface mounting, making it suitable for high-efficiency PCB designs.
The KF80BDT-TR has a positive polarity configuration for standard voltage regulation requirements.
The minimum input voltage is -0.5V, allowing for versatile applications.
It is suitable for industrial, commercial, and consumer electronics applications requiring stable voltage outputs.
This model features a 3-pin construction for easy integration into electronic devices.
It belongs to the KFXX series of low dropout regulators known for stable voltage regulation.
Key features include low dropout voltage, minimal noise, and fast transient response, making it suitable for sensitive electronics.
The country of origin for this model is India.
