RS PRO Circular Connector, 12 Contacts, Front Mount, Socket Female, IP68, 400V, 5A, Polyamide 66 and Polycarbonate 144-4201
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 400V |
| Brand | RS PRO |
| Orientation | Straight |
| Current | 5A |
| Model | 144-4201 |
| IP Rating | IP68 |
| Mount Type | Front |
| Housing Material | Polyamide 66, Polycarbonate |
| Contact Material | Brass |
| Series | RS PRO |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -40°C |
| Pole Format | 12 |
| Contact Plating | Gold |
| Number of Contacts | 12 |
| Contact Gender | Female |
| Shell Size | 21 mm |
| Mating Type | Threaded |
| Connector Size | Standard |
| Plug/Socket | Socket |
| Standards and Approvals | CE, ROHS |
Key Features
- The connector supports a current rating of 5A at 400V.
- It has a threaded mating type with a shell diameter of 21 mm ensuring secure coupling.
- Constructed with a durable polyamide 66 and polycarbonate housing for fire resistance.
- The contacts are gold plated brass for reliable conductivity and corrosion resistance.
- Suitable for harsh environments with a temperature range from -40°C to 85°C.
- Rated IP68, making it waterproof and dust tight for outdoor and indoor use.
- Common applications include factory automation, industrial networking, power connections, lighting and marine equipment.
- The connector orientation is straight, facilitating straightforward installation.
Product Description
RS PRO 144-4201 Circular Connector is a high-quality industrial circular connector designed for rigorous applications requiring secure and reliable connections. This front mount socket features 12 female contacts and supports a voltage rating of 400V with a current capacity of 5A, making it appropriate for power and data connections in industrial environments.
The connector shell size is a standard 21 mm diameter, crafted from fire-resistant polyamide 66 and polycarbonate materials. This ensures enhanced durability and protection against mechanical stresses and environmental conditions. The gold-plated brass contacts provide superior electrical conductivity and resistance to corrosion, vital for maintaining reliable connections over time.
Rated to IP68 standards, the connector is both waterproof and dustproof, suitable for both indoor and outdoor installations in harsh conditions including industrial automation systems, industrial networking, lighting setups, communications equipment, and marine applications.
The mating type is threaded, providing a secure and stable coupling to prevent accidental disconnection during operation. The termination is solder-based, which enhances the mechanical and electrical integrity of the wiring connection.
The RS PRO circular connector is designed to operate safely within a wide temperature range of -40°C to 85°C, making it reliable in varied climates and working environments. Its straight orientation facilitates easy installation in confined areas.
The connector supports a current rating of 5A at 400V. Threaded coupling mechanism to ensure a tight and durable connection. Durable polyamide 66 and polycarbonate housing rated IP68 for waterproof and dustproof protection.
Gold-plated brass contacts for excellent conductivity and longevity. Solder termination for stable terminations. Operating temperature range from -40°C to 85°C for harsh environment compatibility. Suitable for industrial automation, power connection, lighting, communications, and marine equipment.
Complies with CE and ROHS standards.
This RS PRO circular connector offers a robust, professional-grade solution for industrial and manufacturing settings requiring secure electrical connections that can withstand heavy use and challenging environmental factors.
Explore more Industrial Circular Connectors and trusted RS PRO solutions on EnvMart for reliable connectivity components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The connector supports a maximum voltage rating of 400V and a current rating of 5A.
It is constructed from polyamide 66 and polycarbonate, providing fire resistance and durability.
This model has an IP68 rating, making it waterproof and dustproof for both indoor and outdoor use.
It features a straight orientation and is designed for front mounting.
The shell diameter of this connector is 21 mm.
This circular connector has 12 female contacts.
It utilizes a solder termination type for stable connections.
The connector operates safely within a temperature range from -40°C to 85°C.
It is suitable for applications in factory automation, industrial networking, power connections, lighting, and marine equipment.
The contacts are made of brass and are gold plated for enhanced conductivity and corrosion resistance.
This model complies with CE and ROHS standards.
It features a threaded mating type, ensuring a secure and stable coupling to prevent accidental disconnection during operation.
