HARWIN M20 Series Straight Through Hole PCB Socket 6-Contact 2 Row 2.54 mm Pitch M20-7830346
Specifications
| Country of Origin | China |
|---|---|
| Brand | HARWIN |
| Orientation | Straight |
| Current | 12A |
| Model | M20-7830346 |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Bronze |
| Series | M20 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Sub Type | Socket Strip |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Standards/Approvals | RoHS |
| Contact Plating | Tin over Nickel |
| Number of Contacts | 6 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- Compact M20 series socket suitable for dense PCB layouts.
- Constructed with high-temperature nylon housing for durability.
- Features dual beam female bronze contacts plated with tin over nickel.
- Supports current rating up to 12A per contact.
- Suitable for operating temperatures from -40°C to 105°C.
- Designed for through hole mounting with solder termination.
- Meets RoHS compliance standards for environmental safety.
- High reliability with up to 300 mating operations possible.
Product Description
HARWIN M20-7830346 is a Straight Through Hole PCB Socket featuring 6 contacts arranged in 2 rows with a 2.54 mm pitch, specifically designed for board-to-board connector systems.
This M20 series socket offers a compact design with high-temperature nylon housing compliant with UL94V-0 standards, capable of withstanding reflow soldering processes. The female contacts are made of bronze and plated with tin over nickel to ensure excellent electrical connectivity and corrosion resistance.
Rated to carry up to 12 amps per contact, it supports a wide operating temperature range from -40 degrees Celsius to 105 degrees Celsius, making it suitable for diverse industrial and commercial applications.
The connector utilizes a through hole mount method with solder termination, ensuring strong mechanical and electrical bonds on printed circuit boards. Its durable dual beam contacts offer improved connection reliability and can withstand up to 300 mating cycles.
Suitable uses include embedded PCs, motherboards, large electronic systems, consumer electronics, communication equipment, industrial monitoring, and personal computing devices. The product meets RoHS standards, ensuring environmental compliance across electronic component recycling and manufacturing.
Compact M20 series design for increased PCB density and height restrictions. High-temperature thermoplastic nylon housing for reflow solder resistance. Bronze female contacts plated with tin over nickel for durability. Supports board-to-board connector systems with straight orientation.
Current rating up to 12A per contact for high power applications. Operating temperature range from -40°C to 105°C enhances versatility. Through hole mounting with solder termination ensures secure PCB attachment. Meets RoHS environmental directives.
Capable of 300 mating operations ensuring long-term reliability. Manufactured in China under stringent quality standards.
This HARWIN M20 Series PCB Socket is an excellent choice for industrial, electronics manufacturing, communication, and computing projects requiring robust, high-density connectors.
Explore more PCB connectors and components on EnvMart for comprehensive electronics assembly solutions.
