STMicroelectronics Current Sensing Amplifier Single Channel 2.7-5.5 V Supply 80dB CMRR SO-8 TSC2012HYDT
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.75mm |
| Length | 5mm |
| Model | TSC2012HYDT |
| Mount Type | Surface |
| Series | TSC2012 |
| Maximum Operating Temperature | 150°C |
| Package Type | SO-8 |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Pin Count | 8 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 2.7V |
| Supply Current | 5mA |
| GBP - Gain Bandwidth Product | 490kHz |
| CMRR - Common Mode Rejection Ratio | 80dB |
Key Features
- Operates with supply voltage range from 2.7 V to 5.5 V.
- High common-mode rejection ratio of 80 dB for accurate sensing.
- Low offset voltage of ±200 µV and offset drift of 5 µV/°C.
- Gain bandwidth product is 490 kHz enabling fast signal response.
- Wide operating temperature range from -40°C to 150°C compliant with AEC-Q100 standards.
- Surface mount type with compact 5 mm length and 1.75 mm height footprint.
- Designed for precise bidirectional current sensing using shunt resistors.
- Supply current consumption is a low 5 mA to minimize power usage.
Product Description
STMicroelectronics TSC2012HYDT is a precision current sensing amplifier designed for industrial, automotive, and electronic applications that require accurate current measurement over a wide voltage range.
This single-channel amplifier operates with a supply voltage between 2.7 V and 5.5 V and offers a common-mode voltage range from -20 V to +70 V, enabling its use in diverse power systems and battery monitoring circuits.
The device exhibits a high common-mode rejection ratio (CMRR) of 80 dB which effectively minimizes noise in current sensing signals. It senses very low drop voltages down to 10 mV full scale, minimizing measurement errors often encountered in shunt resistor applications.
Key technical parameters include a gain bandwidth product of 490 kHz for fast response, offset voltage within ±200 µV, and offset drift limited to 5 µV/°C, enhancing measurement stability over temperature variations.
The TSC2012HYDT package is an 8-pin SO-8 surface mount type measuring 5 mm in length and 1.75 mm in height, optimized for compact PCB designs. It is rated for operation in harsh environments with a temperature range from -40°C to 150°C and complies with automotive-grade AEC-Q100 certification.
Single channel current sensing amplifier in SO-8 package. Wide supply voltage range from 2.7 V to 5.5 V. High common-mode rejection ratio (80 dB) for superior noise immunity. Low offset voltage and offset drift ensure precise readings.
Wide operating temperature range and automotive standard compliance. Compact dimensions and surface mount design for easy integration.
This amplifier is ideal for electronics manufacturing, automotive battery monitoring, industrial control systems, and power management applications requiring durable current measurement components.
Explore other amplifiers and semiconductor components at EnvMart for your industrial and electronics projects.
Explore more products in our Current Sensing Amplifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates with a supply voltage range from 2.7 V to 5.5 V.
It has a high common-mode rejection ratio of 80 dB, which helps in minimizing noise in current sensing signals.
The gain bandwidth product is 490 kHz, enabling fast signal response.
It is rated for operation in a wide temperature range from -40°C to 150°C.
The amplifier features a low offset voltage of ±200 µV, enhancing measurement accuracy.
This unit has a compact footprint measuring 5 mm in length and 1.75 mm in height.
It is a single-channel current sensing amplifier.
The TSC2012HYDT is designed for surface mount applications.
It consumes a low supply current of 5 mA, which helps to minimize power usage.
It complies with the AEC-Q100 automotive standard, making it suitable for automotive applications.
This amplifier is suitable for applications in industrial control systems, automotive battery monitoring, and power management.
The offset drift is limited to 5 µV/°C, ensuring stability over temperature variations.
