i-Autoc KSV Series Solid State Relay DIN Rail Mount 230V AC Coil 25mA Control Current 20A Switching Current KSV240A20-LM

i-Autoc KSV240A20-LM Solid State Relay is engineered for robust industrial applications requiring reliable electrical switching and control. This DIN rail mounted SSR integrates an efficient heatsink and is suitable for 230V AC coil operation with a low coil current of 25mA. It provides a switching current of 20A using SCR output technology optimized for single-phase AC loads.

Designed for mounting on a standard 35 mm DIN rail or panel screw mounting, this relay offers flexibility in installation. The compact form factor with precise dimensions of 100mm length, 30.5mm width, and 112.5mm height simplifies integration into control panels and electrical enclosures. Featuring PCB terminal connections, it assures secure and stable electrical interfacing.

Notable features include zero crossing switching to minimize electrical noise and surges, LED status indication for operational feedback, and a built-in RC snubber circuit to enhance relay longevity and protect against voltage spikes. This Solid State Relay operates reliably across a wide temperature range from -30°C to 80°C, making it suitable for diverse environments.

This product complies with RoHS standards, affirming its conformity to environmental and safety regulations. Its dielectric strength of 4000 Vrms AC ensures insulation and operator safety.

Typical industrial use cases include automation systems, electrical control panels, HVAC equipment, manufacturing machinery, and anywhere precise control of AC power is required with minimal mechanical wear.

Operates with a 230V AC coil voltage. Mounting designed for 35mm DIN rail or panel fixing. 20A switching current with SCR output technology. Integrated heatsink for thermal management. Zero crossing switching reduces electrical noise and wear.

Operating temperature range from -30°C to 80°C ensures versatility. PCB terminal connections for secure wiring. Compact size for easy panel installation. LED status indication and built-in RC snubber circuit enhance reliability.

RoHS compliant and manufactured in China. Explore more Solid State Relays and related automation components on EnvMart to find the right solution for your electrical control needs.
